VG2755

27” Advanced Ergonomics Business Monitor

USB Type-C
Full HD 1080p resolution
Frameless bezel
SuperClear® IPS technology
VGA, HDMI and DisplayPort inputs

Sales Enquiry

OVERVIEW

The ViewSonic VG2755 is a 27’’ (27’’ viewable) 1080P IPS monitor designed to fit the modern office space. The monitor comes with a built-in USB Type-C port and a complimentary USB Type-C cable. Charge and display content simply via a single cable from your device, enabling connection to your laptop through a single USB cable and keeping your workstation neat while also functioning as a docking monitor. In addition, the monitor is equipped with DisplayPort, HDMI, VGA, and three USB Type-A ports to expand your efficiency. The three-sided frameless bezel design lets you enjoy an uninterrupted view of content across multiple monitors. An advanced ergonomic design offers the widest range of adjustments available for maximum comfort; including pivot, swivel, height adjustment, and an impressive 40° tilt, allowing you to use the monitor while standing or have strategic group discussions around the screen. The packaging is environmentally friendly and offers quick and easy out-of-the-box setup, making VG2755 series monitors perfect for business environments.

Big Convenience in a Single Cable

A built-in USB Type-C port provides unparalleled compatibility with most peripherals.
Get an easy charge for a variety of devices with up to 60W of power, and transmit audio and video simply with one cable.
*Only available for devices that support USB Type-C video streaming. Check to see if your device is compatible for USB Type-C video transmission
**All VG55 Series monitors come with a complimentary USB Type-C cable.

USB Type-C

60W power charge

Transmit data, video, and audio

A New Angle on Workplace Ergonomics

Enjoy every detail with advanced ergonomics including pivot, swivel, and height adjustment to provide maximum comfort. The VG2755 features a 40° ergonomic tilt angle, enabling you to use the monitor while standing or have strategic group discussions around the screen.

Pivot +/-90°

Swivel +/-60°

Tilt 40°~-5°

Height adjustment 0~130mm

Uninterrupted Viewing

The VG2755 is designed with a frameless bezel on three sides, giving the monitor a clean look and an uninterrupted view when used in a multi-monitor setup.

Three-sided frameless bezel

Clarity from Any Angle

Indulge in accurate and vivid colours with consistent levels of brightness from any vantage point. With SuperClear® IPS panel technology, the monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.

SuperClear IPS

178°/178°

Connection Flexibility

In addition to the USB Type-C connection, HDMI, DisplayPort, VGA, and USB 3.2 inputs enable you to connect to an array of devices to the VG2755.

HDMI

DisplayPort

VGA

USB Type-C

USB 3.2 x 4 (1 upstream, 3 downstreams)

vDisplay Manager

ViewSonic’s proprietary vDisplay Manager software is available for free and allows users to organise and divide their screen into multiple segments. The software also enables users to adjust their monitor settings via the software directly for a more efficient workflow.

Spilt screen

Monitor settings

Learn More

Versatile Stand Design

The VG2755’s versatile stand is client mount compatible and features in-built cable management to keep your workstation neat and free of cable clutter. A carrying handle sits at the top of the stand for portability and stability when relocating the monitor.
*Client Mount Kit must be used in conjunction with a mini PC and is sold separately.

Client mount compatible

Cable management

Carrying handle

Environmentally Friendly Packaging

Designed with the environment in mind, the packaging for the VG48/VG55/VG55-2K series is made with up to 80% recyclable and paper based materials instead of hazardous EPS (polystyrene). Additional plastic materials, such as handles, have been replaced with hand holes and the exterior of the package uses mono color printing.

Paper-based packaging

VESA Compatible

Mount the monitor exactly to your liking by utilising the monitor’s 100 x 100mm VESA compatible design.

100 x 100mm

VESA Compatible (Wall Mount 100 x 100 mm)
Menu Control Panel
USB 3.1 down stram x 2
AC In
DisplayPort
HDMI
VGA
USB Type C
USB 3.1 up stream
USB 3.1 down stream

Viewing Modes for Different Occasions

The VG2755 monitor features ViewSonic’s exclusive ViewMode, including , Web, Movie, Mono, Mac, and Game presets. Depending on the occasion, a corresponding preset helps to enhance gamma curve, colour temperature, contrast, and brightness to deliver an optimised viewing experience.

Text

Web

Movie

Mono

Mac

Game

Advanced Eye Care Technology

Flicker Free

Blue Light Filter

Low Energy Consumption

The VG2755 has been designed with energy efficiency in mind. With certification from Energy Star and EPEAT, the VG2755’s Eco Mode consumes less power, resulting in a smaller carbon footprint and reduced overhead costs.

Energy Star

EPEAT

SPECIFICATIONS

Display
Display Size (in.): 27
Viewable Area (in.): 27
Panel Type: IPS Technology
Resolution: 1920 x 1080
Resolution Type: FHD (Full HD)
Static Contrast Ratio: 1,000:1 (typ)
Dynamic Contrast Ratio: 50M:1
Light Source: LED
Brightness: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + FRC)
Aspect Ratio: 16:9
Response Time (Typical GTG): 5ms
Response Time (GTG w/OD): 5ms
Response Time (Typical Tr+Tf): 15ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 60
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 102% size / 94% coverage (Typ)
Pixel Size: 0.311 mm (H) x 0.311 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
PC Resolution (max): 1920x1080
Mac® Resolution (max): 1920x1080
PC Operating System: Windows 7/8/8.1/10 certified; macOS tested
Mac® Resolution (min): 1920x1080
Connector
VGA: 1
USB 3.2 Type A Down Stream: 3
USB 3.2 Type B Up Stream: 1
USB 3.2 Type C Up Stream; DisplayPort Alt mode : 1 (60W power charger)
HDMI 1.4: 1
DisplayPort: 1
Power in: 3-pin Socket (IEC C14 / CEE22)

Audio
Internal Speakers: 2Watts x2
Power
Eco Mode (Conserve): 13W
Eco Mode (optimized): 15.6W
Consumption (typical): 19.1W
Consumption (max): 22.54W
Voltage: AC 100-240V
Stand-by: 0.3W
Power Supply: Internal Power Supply
Additional Hardware
Kensington Lock Slot: 1
Cable Organization: Yes
Controls
Physical Controls: Key 1 (eye), Key 2, Key 3, Key 4, Key 5, Key 6 (power)
On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90%
Wall Mount
VESA Compatible: 100 x 100 mm
Input Signal
Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz, DisplayPort (v1.2): 15 ~ 82KHz, Type C: 15 ~ 82KHz
Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 24 ~ 75Hz, DisplayPort (v1.2): 24 ~ 75Hz, Type C: 24 ~ 75Hz
Video Input
Digital Sync: TMDS - HDMI (v1.4), PCI-E - DisplayPort (v1.2), Micro-Packet - Type C
Analog Sync: Separate/Composite/SOG - RGB Analog
Ergonomics
Height Adjust (mm): 130
Swivel: 120º
Tilt (Forward/Back): -5º / 40º
Pivot (Right/Left): 90º / 90º
Weight (imperial)
Net (lbs): 16.5
Net Without Stand (lbs): 11.2
Gross (lbs): 23.6
Weight (metric)
Net (kg): 7.5
Net Without Stand (kg): 5.1
Gross (kg): 10.7
Dimensions (imperial) (wxhxd)
Packaging (in.): 27.2 x 16.9 x 8.6
Physical (in.): 24.1 x 15.99~20.99 x 8
Physical Without Stand (in.): 24.1 x 14.2 x 2
Dimensions (metric) (wxhxd)
Packaging (mm): 692 x 430 x 218
Physical (mm): 612 x 406.19~533.24 x 202
Physical Without Stand (mm): 612 x 362 x 52
General
Regulations: cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS
PACKAGE CONTENTS: VG2755 x1, 3-pin Plug (IEC C13 / CEE22) x1, DisplayPort Cable (v1.2; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market
Power Management: Energy Star standards, EPEAT
