- REGULATIONS
TCO ́99, TÜV/GS, TÜV/Ergo, ISO 13406-2 (pixel failure class II), TÜV-S, UL, cUL, FCC-B, CB, CE, NOM, Energy Star, GOST-R, Hygienic, SASO, BSMI, CCC, PSB, C-TICK, PCBC, VCCI
- PACKAGE CONTENTS
LCD display, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
- AUDIO
Speaker: 2 x 3-watt
Amplifier: 3watt@1khz@THD≤8%
- CONNECTOR
Analogue: 15-pin mini D-sub (detachable cable)
Digital: DVI-D (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in
- POWER
Voltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: 50 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Soft power, menu [1] , down, up, select [2], mute, volume up/down
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), audio adjust (volume, mute), colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 10% to 90% (non-condensing)
- WEIGHT
Net: 7kg (w/ stand); 5.3kg (w/o stand)
- VIDEO INPUT
Frequency: Fh: 30 – 82kHz, Fv: 50 – 75Hz
Analogue: RGB analogue (0.7 Vp-p , 75 ohms)
Digital: DVI-D (TMDS, 100 ohms)
Sync: H/V separated (TTL)
- POWER MANAGEMENT
Meets TCO’99, ENERGY and Energy Star standards
- ERGONOMICS
Tilt: Down 5°, up 20°
