- REGULATIONS
TCO‘99, TÜV/GS, TÜV/Ergo, ISO 13406-2 (pixel failure class II), TÜV-S, UL,
cUL, FCC-B, CB, CE, NOM, GOST-R (Hygienic), SASO, PCBC, BSMI, CCC,
Green Mark, Energy Star®, (PSB), (C-TICK), MIC
- PACKAGE CONTENTS
LCD display, power cable, 15-pin VGA cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD (User Guide/drivers)
- AUDIO
Speaker: Integrated stereo speakers
- CONNECTOR
Analogue: 15-pin mini D-sub (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio In: 3.5mm stereo audio line-in
- POWER
Voltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: 47 watt (typ.), <2 watt in power save mode
- CONTROLS
Basic: Power, menu [1], down, up, select [2], mute, volume up/down, main power
OSD: Auto image adjust, contrast, brightness, ViewMatch® colour adjust (sRGB,
9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency,
pixel clock, model number, serial number, website), manual image adjust
(H. size, H/V position, fine tune, sharpness), setup menu (language,
resolution notice, OSD position, OSD timeout, OSD background),
OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C – 40°C
Humidity: 10% – 90% (non-condensing)
- WEIGHT
Net With Stand: 5.5kg (w/ stand)
Net Without Stand: 4.9kg (w/o stand)
- VIDEO INPUT
Frequency: Fh: 30 - 94kHz, Fv: 50 - 75Hz
Sync: H/V separated (TTL)
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohms)
- POWER MANAGEMENT
Meets TCO’99 and Energy Star® standards
- ERGONOMICS
Down 5°, up 20°
