VX2262wm

22" WIDESCREEN LCD WITH 20,000:1 DYNAMIC CONTRAST

Bize Sorun

FOTOĞRAFLAR

ÜRÜNE GENEL BAKIŞ

ViewSonic’s 22" VX2262wm widescreen LCD offers the perfect balance of performance and style. With its elegant lines, the VX2262wm fits beautifully into your office décor and its high performance features BLEND EFFORTLESSLY INTO YOUR TECHNOLOGY LIFESTYLE. Images leap from the screen with 1680x1050 resolution, video response as fast as 2msand 20,000:1 DYNAMIC CONTRAST RATIO. Scrolling text, Internet pages and spreadsheet applications are Displayed in crisp, blur-free detail with precise color The SRS WOW HD sound* powerfully complements your games, movies and other multimedia applications. Demanding designers, professionals and gamers will love the sophisticated performance of the 22" VX2262wm.

High performance in a beautiful design

TEKNIK ÖZELLIKLER

COLORS
Black
LCD
Tür: 56cm / 22" Wide Color TFT Active Matrix LCD
Kontrast Oranı: 1000:1 static (typ), 20,000:1 dynamic
Görüntüleme Açıları: 170º horizontal, 160º vertical @ contrast ratio > 10:1

170° horizontal, 170° vertical @ contrast ratio > 5:1
Parlaklık: 300cd/m²
Ekran Alanı: 474mm x 296mm, 16.1" horizontal x 10.0" vertical; 22.0" diagonal
Optimum Çözünürlük: 1680x1050
Yanıt Süresi: up to 2ms (gray-to-gray); 5ms black-to-white (typ)
Işık Kaynağı: Long life, 50,000 hrs. (typ)
Panel Yüzeyi: Anti-glare
UYUM
PC: VGA up to 1680x1050 non-interlaced
Mac®: G3/G4/G5 up to 1680x1050

BOYUTLAR
Stand İle Birlikte Fiziksel: 508mm x 440mm x 203mm (20.0" x 17.3" x 7.9")
Stand Olmadan Fiziksel: 508mm x 359mm x 64mm (20.2" x 14.1" x 2.5")
YÖNETMELİKLER
UL, cUL, FCC-B, CB, CE, ENERGY STAR®, NOM, WEEE TUV-S/IRAM/UL-AR S Mark), ICES-B, ISO 13406-2 & MPR II), GOST-R + 20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, MIC, Green Mark, RoHS, EPEAT-Silver
PAKET İÇERİĞİ
LCD display, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD
Ses
Hoparlörler: 2x2-watt SRS WOW HD (Requires SRS Audio Sandbox Software to be installed.)
GERİ DÖNÜŞÜM/ATMA
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
KONEKTÖRLER
Güç: 3-pin AC plug (CEE22)
Analog/Dijital : 15-pin mini D-sub/DVI-D
Güç
Gerilim: AC 100-240V, 50-60Hz (auto switch)
Tüketim : 45W (typ)
KONTROLLER
Temel: Power, 1, down, up, 2
OnView®: Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch® color adjust (sRGB, 9300K, 7500K, 6500K-default, 5400K, user color-RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number), manual image adjust (H. size, H. position, V. position, fine tune, sharpness, dynamic contrast comma aspect ratio, response time)), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall
İŞLETİM KOŞULLARI
Isı: 32-104°F (0-40°C)
Nem: 10-90% (non-condensing)
Ağırlık
Stand İle Birlikte Net: 5.6 kg (12.2 lb.)
Stand Olmadan Net: 4.5 kg (9.9 lb.)
Stand İle Birlikte Brüt: 7.7 kg (16.9 lb.)
Video Girişi
Analog/Dijital: RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (HDCP)
Frekans: Fh: 24~83kHz, Fv: 50~76Hz
Senk.: H/V separated (TTL), composite, sync-on-green
GÜÇ YÖNETİMİ
Meets MPRII and ENERGY STAR® standards
Ergonomik Özellikler
Eğilme: -5/+20º
