- РАЗМЕРЫ
Физические с подставкой: 508mm x 440mm x 203mm (20.0" x 17.3" x 7.9")
Физические без подставки: 508mm x 359mm x 64mm (20.2" x 14.1" x 2.5")
- ИНСТРУКЦИЯ
UL, cUL, FCC-B, CB, CE, ENERGY STAR®, NOM, WEEE TUV-S/IRAM/UL-AR S Mark), ICES-B, ISO 13406-2 & MPR II), GOST-R + 20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, MIC, Green Mark, RoHS, EPEAT-Silver
- СОДЕРЖИМОЕ УПАКОВКИ
LCD display, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD
- АУДИО
Динамики: 2x2-watt SRS WOW HD (Requires SRS Audio Sandbox Software to be installed.)
- ПЕРЕРАБОТКА
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
- СОЕДИНЕНИЕ
Питание: 3-pin AC plug (CEE22)
Analogue/Digital: 15-pin mini D-sub/DVI-D
- Питание
Напряжение : AC 100-240V, 50-60Hz (auto switch)
Потребление: 45W (typ)
Meets MPRII and ENERGY STAR® standards
- СРЕДСТВА УПРАВЛЕНИЯ
Основные: Power, 1, down, up, 2
OnView®: Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch® color adjust (sRGB, 9300K, 7500K, 6500K-default, 5400K, user color-RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number), manual image adjust (H. size, H. position, V. position, fine tune, sharpness, dynamic contrast comma aspect ratio, response time)), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall
- УСЛОВИЯ ЭКСПЛУАТАЦИИ
Температура: 32-104°F (0-40°C)
Влажность: 10-90% (non-condensing)
- ВЕС
Net With Stand: 5.6 kg (12.2 lb.)
Нетто без подставки: 4.5 kg (9.9 lb.)
Гросс с подставкой: 7.7 kg (16.9 lb.)
- Видео входы
Analogue/Digital: RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (HDCP)
Частота: Fh: 24~83kHz, Fv: 50~76Hz
Синх.: H/V separated (TTL), composite, sync-on-green
- Эргономика
Наклон: -5/+20º
