Q2202wb
56 cm / 22" (21.6" VIEWABLE) WIDESCREEN LCD WITH SUPER-FAST 5MS VIDEO RESPONSE
OVERVIEW
The Optiquest® Q2202wb 55 cm / 21.6" widescreen LCD is the big screen choice for users on a budget. You won’t sacrifice performance for price with this display. It combines high brightness and contrast ratio with 5ms video response for CRYSTAL-CLEAR, BLUR FREE VIDEO, TEXT AND GRAPHICS. The super-high 1680x1050 resolution reduces eye fatigue and ensures text and graphics are crisp. The widescreen lets you work in two applications or documents side-by-side, so you get more done in less time. The integrated power supply and VESA® wall-mount compliance reduce clutter and free up valuable desktop real estate. Furnish your desktop in style with the budget-friendly, stylish Q2202wb.Affordable widescreen performance.
SPECIFICATIONS
- COLORSBlack
- LCDТип: 56 cm / 22" (21.6" viewable) color TFT active matrix WSXGA LCD
КОНТРАСТНОСТЬ: 1000:1 (typ)
Углы обзора: 170º horizontal, 160º vertical @ contrast ratio > 10:1
170° horizontal, 170° vertial @ contrast ratio 5:1
Яркость: 300 cd/m2 (typ)
Обрасть отображения: 46 cm/ 18.3" horizontal x 29 cm / 11.4" vertical; 55 cm / 21.6" diagonal
Оптимальное разрешение: 1680x1050
Время отклика (тип.): 5ms (typ)
Ресурс лампы: Long life, 50,000 hrs. (typ)
Поверхность панели: Anti-glare - СОВМЕСТИМОСТЬПК: VGA up to 1680x1050 (non-interlaced)
Mac®: G3/G4/G5 up to 1680X1050
- РАЗМЕРЫФизические с подставкой: 526mm x 433mm x 173mm (20.7" x 17.0" x 6.8")
Физические без подставки: 526mm x 371mm x 75mm (20.7" x 14.6" x 3.0") - ИНСТРУКЦИЯUL, cUL, FCC-B, NOM, ENERGY STAR®, TUV-S, CE, ISO13406-2 Class II, WEEE, RoHS, GOST-R / Hygenic
- СОДЕРЖИМОЕ УПАКОВКИLCD display, power cable, video cable, User Guide
- ГАРАНТИЯOne-year limited warrranty on parts, labor and backlight
- ПЕРЕРАБОТКАThe lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
- СОЕДИНЕНИЕАналоговый: 15-pin mini D-sub
Питание: 3-pin AC plug (CEE22) - ПитаниеНапряжение : AC 100–240V (universal), 50–60Hz (auto switch)
Потребление: 45W (typ)
ENERGY STAR® standards - СРЕДСТВА УПРАВЛЕНИЯОсновные: Power, 2, up, down, 1
OnView®: Auto image adjust, brightness, contrast, color adjust (sRGB, 9300K, 6500K, 5400K, user color), H. position, V. position, H. size, resolution notice, OSD position, OSD timeout, OSD background, fine tune, sharpness, language, input select, recall - УСЛОВИЯ ЭКСПЛУАТАЦИИТемпература: 32-104ºF (0-40ºC)
Влажность: 20-80% (non-condensing) - ВЕСNet With Stand: 4.6 kg (10.1 lb. )
Нетто без подставки: 4.5 kg (9.8 lb. )
Гросс с подставкой: 5.8 kg (12.8 lb. ) - Видео входыЧастота: Fh: 30~80kHz, Fv: 55~75Hz
Синх.: H/V separated (TTL)
Аналоговый: RGB analog (75 ohms, 0.7 Vp-p) - ЭргономикаНаклон: –5º/+15º
