VA2201-H
22" Full HD Monitor
- SuperClear® VA panel technology
- Eye-care technology for comfortable viewing
- Eco-mode for low energy consumption
- ViewMode color rendering options
- Adaptive sync 75Hz to eliminate screen tearing & reduce stuttering
- HDMI and VGA Input for connectivity
OVERVIEW
The ViewSonic VA2201-H is a 22” Full HD monitor with HDMI and VGA input for business or home usage. Delivering a stunning image quality with low power consumption, this monitor provides six ViewMode presets that deliver optimized screen performance in different applications. Even if used for games, users can move without screen tearing. Besides, the Eye-Care technology helps to eliminate eyestrain from extended viewing periods. With VESA-compatible mount support, this monitor is easy to setup on the wall.SuperClear® Technology for Clarity from Any Angle
Improve group collaboration with high contrast ratio, consistent brightness, and unwavering image quality from every angle with SuperClear® VA panel technology.
Full HD 1080p Resolution
Experience incredible clarity and detail through Full HD 1920x1080 resolution, providing an unbelievable pixel-by-pixel performance for outstanding entertainment.
Comfortable Viewing
Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.Eye-Care Technology

No Screen Tearing & Less Stuttering for Moving Objects
To meet a variety of frame rates from videos or games, the Adaptive Sync provides a wide variable refresh rate of 75 Hertz support to avoid screen tearing.Adaptive Sync 75 Hz

Color Rendering Options
ViewSonic’s unique ViewMode feature offers “Game”, “Movie”, “Web”, “Text”, and “Mono” presets. These presets enhance gamma curve, color temperature, contrast, and brightness to deliver an optimized viewing experience for different screen applications.ViewMode: Game/Movie/Web/Text/Mono/Mac

Low Energy Consumption
This monitor has been designed with energy efficiency in mind, featuring an Eco Mode that consumes less power, resulting in a smaller carbon footprint and reduced office overhead costs.Eco-Mode

Flexible Connectivity
HDMI and VGA inputs give you the freedom to connect your monitor to a wide range of devices.
Dimensions & I/O Ports

- Menu Control Panel
- VESA Compatible
(Wall Mount 100 x 100mm) - HDMI
- VGA
- DC in
SPECIFICATIONS
- DisplayDisplay Size (in.): 22
Viewable Area (in.): 21.5
Panel Type: VA Technology
Resolution: 1920 x 1080
Resolution Type: FHD
Static Contrast Ratio: 3,000:1 (typ)
Dynamic Contrast Ratio: 50M:1
Light Source: LED
Brightness: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit true
Aspect Ratio: 16:9
Response Time (Typical GTG): 4ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 75
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 100% size (Typ)
Pixel Size: 0.249 mm (H) x 0.241 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H) - CompatibilityPC Resolution (max): 1920x1080
Mac® Resolution (max): 1920x1080
PC Operating System: Windows 10 certified; macOS tested
Mac® Resolution (min): 1920x1080 - ConnectorVGA: 1
HDMI 1.4: 1
Power in: DC Socket (Center Positive)
- PowerEco Mode (Conserve): 15W
Eco Mode (optimized): 18W
Consumption (typical): 22W
Consumption (max): 24W
Voltage: AC 100-240V
Stand-by: 0.5W
Power Supply: External Power Adaptor - Additional HardwareKensington Lock Slot: 1
- ControlsPhysical Controls: Key 1 (favorite), Key 2, Key 3 (power), Key 4, Key 5
On Screen Display: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu - Operating ConditionsTemperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90% - Wall MountVESA Compatible: 100 x 100 mm
- Input SignalFrequency Horizontal: 24 ~ 86KHz
Frequency Vertical: 48 ~ 75Hz - Video InputDigital Sync: TMDS - HDMI (v1.4)
Analog Sync: Separate - RGB Analog - ErgonomicsTilt (Forward/Back): -3º / 20º
- Weight (imperial)Net (lbs): 5.3
Net Without Stand (lbs): 4.9
Gross (lbs): 7.7 - Weight (metric)Net (kg): 2.4
Net Without Stand (kg): 2.2
Gross (kg): 3.5 - Dimensions (imperial) (wxhxd)Packaging (in.): 21.9 x 13.8 x 4.7
Physical (in.): 19.4 x 14.4 x 6.5
Physical Without Stand (in.): 19.4 x 11.3 x 1.6 - Dimensions (metric) (wxhxd)Packaging (mm): 555 x 350 x 120
Physical (mm): 492 x 367 x 165
Physical Without Stand (mm): 492 x 288 x 40 - GeneralRegulations: REACH, WEEE
PACKAGE CONTENTS: VA2201-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market
