- DIMENSIONS
W x H x D mm: 468 x 403 - 538 x 315 (w/stand)
448 x 346 x 66 (w/o stand)
- REGULATIONS
TCO 99, TÜV/GS, TÜV/Ergo, ISO 13406-2 (pixel failure class II), TÜV S, UL, cUL, FCC-B (ICES), CB, CE, ICES-003B, NOM, ENERGY, Energy Star, GOST-R, Hygienic, SASO, KTL/MIC, BSMI, CCC, PSB, C-TICK, WEEE, RoHS
- PACKAGE CONTENTS
LCD monitor, power cable, 15-pin VGA video cable, DVI cable, USB cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers), PerfectSuite™ CD-ROM
- CONNECTOR
Analogue: 15-pin mini D-sub (detachable cable)
Digital: 29-pin Digital DVI-I (analogue and digital) (detachable cable)
USB: 1x upstream (4-pin Typ B)/4x downstream (4-pin Typ A)
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100 – 240V, 50/60Hz (Auto-Switch), internal power supply
Consumption: 52 watt (typ.), < 2 watt in power save mode
- CONTROLS
Basic: Soft power, menu [1] , down, up, select [2], main power
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-A, DVI-D), colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, 5000K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (PIP [PIP,PIP position, PIP swap], H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, input priority, OSD position, OSD timeout, OSD background, OSD pivot), auto white balance, OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 10% to 90% (non-condensing)
- WEIGHT
Net: 9kg (w/stand); 5.2kg (w/o stand)
- VIDEO INPUT
Frequency: Fh: 24 – 92kHz, fv: 50 – 85Hz
Sync: H/V separated (TTL), composite, sync on green
Analogue: RGB analogue (0.7/1.0 Vp-p , 75 ohms)
Digital: DVI (TMDS, 100 ohms)
- POWER MANAGEMENT
Meets TCO’99, ENERGY and Energy Star standards
- ERGONOMICS
Tilt: Down 5°, up 20°
Swivel: 270° (135° left/right)
Height Adjustment: 0~ ≥135mm
Pivot: 0°~ 90°
