- REGULATIONS
TCO’03, CE, CB, TÜV/GS, TÜV/ERGO, ISO13406-2 (pixel fault class
II), UL, cUL, FCC-B, ENERGY, EPA Energy Star, NOM, GOST-R,
(SASO), ICES 003, BSMI, CCC, PSB, (C-TICK), TÜV-S
- PACKAGE CONTENTS
LCD display, power cable, 15-pin VGA video cable,Quick Start Guide, ViewSonic Wizard CD
- INPUT
Sync: H/V separated (TTL)
Frequency: Fh: 30-82kHz, Fv: 50-85Hz
Video: RGB analogue (75 ohms, 0.7 Vp-p)
- CONNECTOR
Analogue: 15-pin mini D-Sub (attached cable)
Power: 3-pin AC plug, (CEE22)
- POWER
Voltage: AC 100–240V, 50–60Hz (auto switch), internal power supply
Consumption: 35W (typ.); ≤ 1 watt in power save mode
- CONTROLS
OSD: Auto image adjust, brightness, contrast, ViewMatch® colour adjust
[sRGB, 9300K, 6500K (default), 5400K, user colour (R,G,B)],
information [resolution, H. frequency, V. frequency, pixel clock,
model number, serial number], manual image adjust [H. size,
H./V. position, fine tune, sharpness, scaling], setup menu [language
(English, French, German, Italian, Spanish, Finnish, Japanese,
Traditional Chinese, Simplified Chinese), resolution notice, OSD
position, OSD timeout, OSD background], memory recall,
OSD lock, power lock
Physical: Power on/off, menu, down, up, select
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 10% to 90% (non-condensation)
- WEIGHT
Net: 5.4kg
- POWER MANAGEMENT
Meets TCO’03, ENERGY and EPA Energy Star standards
- ERGONOMICS
Tilt: Down 5°, Up 20°
