- REGULATIONS
TCO´03, TÜV/GS, TÜV/Ergo, ISO13406-2 (class 2), UL, c-UL, CB,
CE, FCC-B, CCC, PSB, TÜV-S, ENERGY, EPA EnergyStar, NOM,
GOST-R, (SASO), BSMI, (C-TICK), IRAM, ICES-B
- PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
- CONNECTOR
Signal: 15-pin mini D-Sub (detachable cable)
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100-240V, 50-60Hz (auto-switch), internal power supply
Consumption: <35W (typ.), <1W in suspend mode
- CONTROLS
OSD: Auto Image Adjust, Contrast, Brightness, Colour Adjust [sRGB,
9300K, 6500K (default), 5400K, User (R, G, B)], Information
[Mode, Model Number, Serial Number, Website], Manual Image
Adjust [H. Size, H./V. Position, Fine Tune, Sharpness, Scaling],
Setup Menu [Language (English, French, German, Italian,
Spanish, Finnish, Japanese, Simplified and Traditional Chinese),
Resolution Notice, OSD Position, OSD Timeout, OSD
Background], Memory Recall
Physical: Power on/off, menu, up, down, select
- OPERATING CONDITIONS
Temperature: 0–40°C
Humidity: 10–90% (non-condensing)
- WEIGHT
Net: 4.5kg
- VIDEO INPUT
Frequency: Fh: 30-82kHz, Fv: 50-85Hz
Analogue: RGB Analogue (75 ohms, 0.7 Vp-p)
Sync: H/V separated (TTL)
- POWER MANAGEMENT
Meets TCO, ENERGY STAR and ENERGY standards.
- ERGONOMICS
Down 5°, Up 20°
