- REGULATIONS
TCO’99, TÜV/GS, TÜV/Ergo, ISO 13406-2 (class 2), TÜV S, CE
UL, cUL, IC-B, CB-Report, FCC-B, CB, CE, EPA, NOM, NEMKO,
SEMKO, DEMKO, FIMKO, GOST-R, PCBC, VCCI, BSMI, CCC, PSB,
C-TICK, ENERGY, EnergyStar, PCT (BZ02), Taiwan green mark
- WARRANTY
Please see:
http://www.viewsoniceurope.com/UK/Support/warranty.htm
- AUDIO
Speaker: 2 x 5 watts
Amplifier: 5 watts at 1kHz
- INPUT
Sync: H/V separated (TTL), composite, sync on green
Analogue: RGB analogue (0.7 Vp-p, 75 ohms)
Digital: DVI-D (TMDS, 100 ohms)
Frequency: Fh: 30-82 kHz, Fv: 50-85 Hz
- CONNECTOR
Audio (input/output): 3.5mm stereo connector (line-in)/(line-out)
Headphone: 3.5mm stereo connector
Signal: RGB (15-pin mini D-sub), DVI-D, detachable cable
Power: 3-pin plug (IEC) to External brick, 12 volt DC to Head
- POWER
Voltage: AC 100-240 V (50/60Hz), auto switch
Consumption: 50 watts (max.)
- CONTROLS
OSD: Auto image adjust, contrast, brightness, input select, colour
adjust (sRGB, 9300K, 6500K [default], 5400K, user RGB), information
(mode, model number, serial number, website), manual
image adjust (H/V position, H size, fine tune, sharpness), setup
menu (language, resolution notice, OSD position, OSD timeout,
OSD background), memory recall
Physical: Power (soft), 1, menu up, down, 2, (enter) input select, volume +/-
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 10% to 90% (non-condensation)
- WEIGHT
Net: 5.6 kg
- POWER MANAGEMENT
TCO’99, ENERGY Standards
