- REGULATIONS
TCO’99, CE, CB, NEMKO/GS2, NEMKO ERGO3, ISO13406-2
(pixel failure class II), UL, cUL, FCC-B, ENERGY, NOM, GOST-R + 20
original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB,
C-TICK, Argentina-S, PSE (power adapter), Green Mark
- PACKAGE CONTENTS
LCD display, power cable, 15-pin VGA video cable, DVI cable,
Quick Start Guide, ViewSonic Wizard CD
- WARRANTY
Please see:
www.viewsoniceurope.com/UK/Support/warranty.htm
- INPUT
Sync: H/V separated (TTL), composite, sync-on-green
Frequency: Fh: 30-82kHz, Fv: 50-75Hz
Video: RGB analogue (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Power: 3-pin AC plug, (CEE22)
- POWER
Voltage: AC 100–240V, 50–60Hz (auto switch), internal power supply
Consumption: < 32W (typ); ≤ 1 watt in power save mode
- CONTROLS
Physical: Down 5°, Up 20°
Main Menu: Auto image adjust, brightness, contrast, input select [analogue,
digital], ViewMatch® colour adjust [sRGB, 9300K, 6500K-default,
5400K, user colour - RGB], information [resolution, H. frequency,
V. frequency, pixel clock, model number, serial number], manual
image adjust [H. size, H./V. position, fine tune, sharpness], setup
menu [language (English, French, German, Italian, Spanish, Finnish,
Japanese, Traditional Chinese, Simplified Chinese), resolution
notice, OSD position, OSD timeout, OSD background], memory
recall, OSD lock, power lock
- WEIGHT
Net: 5.0kg (with stand)
- POWER MANAGEMENT
Meets TCO’99, Energy and ENERGY STAR standards
- ERGONOMICS
Tilt: Down 5°, Up 20°
- OPERATING CONDITIONS
Humidity: 10% to 90% (non-condensation)
Temperature: 0°C to 40°C
