- REGULATIONS
TCO’99, NEMKO/GS2, NEMKO/ERGO3, CE, CB, UL, cUL, FCC-B, ENERGY, NOM,
ISO13406-2 (pixel failure class II), GOST-R, VCCI, BSMI, CCC, (PSB), (C-TICK),
Argentina-S, Green Mark
- PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
- WARRANTY
Please see: www.viewsoniceurope.com/UK/Support/warranty.htm
- INPUT
Sync: H/V separate (TTL), composite, sync on green
Analogue: RGB analogue (0.7 Vp-p, 75 ohm)
Digital: DVI-D (TMDS, 100 ohm)
Frequency: Fh: 24 – 82kHz, Fv: 50 – 85Hz
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Audio (input/output): 3.5mm stereo audio line-in
Power: 3-pin (CEE22)
- POWER
Voltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: 35 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power on/off, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), colour adjust
(sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency,
pixel clock, model number, serial number, website), manual image adjust (H/V
position, H size, fine tune, sharpness), setup menu (language, resolution notice,
OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C to 40°C
Humidity: 20% to 90% (non-condensation)
- WEIGHT
Net: 5.0kg (with stand), 3.5kg (without stand)
- POWER MANAGEMENT
LCD Monitor, power cable, 15-pin VGA video cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FPMPMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 20°
- AUDIO
Speakers: 2 x 1 watt
