- DIMENSIONS
Physical With Stand: 510 x 432 x 225
Physical Without Stand: 510 x 355 x 61
W x H x D mm: 564 x 481 x 128
- REGULATIONS
TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R+Hygienic, UL, cUL, FCC-B, NOM, EPEAT, Ukraine, SASO, ENERGY, ENERGY STAR, C-Tick, MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark, CCC, VCCI, Green Mark, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, Quick
Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
(multi-language) (multi-language)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable) (HDCP enabled)
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 38 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select 2]
OSD: Auto image adjust,contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial umber), manual image adjust (H/V position, H size, fine tune, sharpness, aspect ratio [4:3, full screen], response time), setup menu (language, resolution notice, OSD position, OSD timeout, OSD
background), auto white balance, OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C–40°C
Humidity: 10%–90% (non-condensation)
- WEIGHT
Net With Stand: 5.0kg
Gross: 6.6kg
- VIDEO INPUT
Frequency: Fh: 24~82kHz, Fv: 50~75Hz
Sync: H/V separate (TTL), composite, sync on green
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Digital: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
- POWER MANAGEMENT
TCO’03 and ENERGY STAR standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA® FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 20°
