- REGULATIONS
TCO´03, TÜV/GS, ISO 13406-2 (class 2) TÜV-S, TÜV/Ergo, UL,
CUL, FCC-B, CB REPORT, CE, EPA, NOM, NEMKO, SEMKO,
DEMKO, FIMKO, GOST-R, PCBC, VCCI, BSMI, CCC, PSB, C-TICK,
ENERGY
- AUDIO
Speaker: 2x3-watts
Amplifier: 3 watts @1kHz
- CONNECTOR
Audio: 3.5mm audio line-in
Signal: 15-pin mini D-sub, DVI-D2
Power: 3-pin AC plug
- POWER
Voltage: AC 100-240V, 50-60Hz (auto switch), external power supply
Consumption: <36W (typ), ≤1W in power save mode
- CONTROLS
Basic: Power (soft), 1, down, up, 2, mute, volume up, volume down
OSD: Auto image adjust, contrast, brightness input select, audio adjust
(volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500Kdefault,
5400K, 5000K, user colour), information (mode, model
number, serial number), manual image adjust (H. size, H. position,
V. position, fine tune, sharpness), setup menu (language, resolution
notice, OSD position, OSD timeout), memory recall
- OPERATING CONDITIONS
Temperature: 0–40°C
Humidity: 10–90% (non-condensing)
- WEIGHT
Net: 5.3kg
- VIDEO INPUT
Sync: H/V separated (TTL)
Analogue: RGB analogue (75 ohms, 0.7 Vp-p)
Digital: DVI-D (TMDS, 100 ohms)
Frequency: Fh: 30~82kHz, Fv: 50~85Hz
- POWER MANAGEMENT
Meets TCO’03 and ENERGY standards.
