- DIMENSIONS
Physical With Stand: 596mm x 480mm x 254mm (23.5" x 18.9" x 10.0")
Physical Without Stand: 596mm x 406mm x 93mm (23.5" x 16.0" x 3.6")
- REGULATIONS
UL, cUL, FCC-B, CB, CE, NOM, IRAM, NEMKO/ERGO (covers ISO13406-2), BSMI, CCC, ENERGY STAR,® PSB, CTICK, RoHS, WEEE, VCCI, GOST-R, SASO, TCO’03
- PACKAGE CONTENTS
LCD display, video cable, audio cable, power cable,
Quick Start Guide, ViewSonic Wizard (DVI and HDMI cables not included)
- AUDIO
Speaker: 2x2.5 watts
- RECYCLE/DISPOSAL
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
- CONNECTOR
Power: 3-pin AC plug (CEE22)
Analogue/Digital: 15-pin mini D-sub/DVI-D, 19-pin HDMI
- POWER
Voltage: AC 100–240V (universal), 50/60Hz (auto switch)
Consumption: 64W (typ); below 1W in standby mode
- CONTROLS
Basic: Power, 1, down, up, 2
OnView®: Auto image adjust, contrast, brightness, input select (analog, digital, HDMI), ViewMatch® color adjust (sRGB, 9300K, 6500K – default, 5400K, RGB), information, manual image adjust (H. size, H. position, V. position, fine tune, sharpness, display mode, aspect ratio and ECO mode), setup menu etc.), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall
- OPERATING CONDITIONS
Temperature: 41–95°F (5–35°C)
Humidity: 20–80% (non-condensing)
- WEIGHT
Net With Stand: 7.4 kg(16.3 lb.)
Net Without Stand: 5.6 kg(12.3 lb.)
Gross With Stand: 10.1 kg(22.2 lb.)
- VIDEO INPUT
Analog/Digital: RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (HDCP) / HDMI
Frequency: Fh: 24~82kHz, Fv: 50~85Hz
Sync: H/V separated (TTL)
- POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR® standards
- ERGONOMICS
Tilt: -5°/+20°
