- DIMENSIONS
Physical With Stand: 596mm x 480mm x 254mm (23.5" x 18.9" x 10.0")
Physical Without Stand: 596mm x 406mm x 93mm (23.5" x 16.0" x 3.6")
- REGULATIONS
UL, cUL, FCC-B, CB, CE, NOM, IRAM, ERGO (covers ISO13406-2), BSMI, CCC, ENERGY STAR,® PSB, CTICK, RoHS, WEEE, VCCI, GOST-R, SASO, TCO’03
- PACKAGE CONTENTS
LCD display, video cable, power cable,
Quick Start Guide, ViewSonic Wizard (DVI and HDMI cables
not included)
- RECYCLE/DISPOSAL
The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
- CONNECTOR
Analogue: 15-pin mini D-sub
Power: 3-pin AC plug (CEE22
- POWER
Voltage: AC 100–240V (universal), 50/60Hz (auto switch)
Consumption: 64W (typ); below 1W in standby mode
- CONTROLS
Basic: Power, 1, down, up, 2
OnView®: Auto image adjust, contrast, brightness, input select (analog, digital, HDMI), ViewMatch® color adjust (sRGB, 9300K, 6500K – default, 5400K, RGB), information, manual image adjust (H. size, H. position, V. position, fine tune, sharpness, display mode, aspect ratio and ECO mode), setup menu etc.), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall
- OPERATING CONDITIONS
Temperature: 41–95°F (5–35°C)
Humidity: 20–80% (non-condensing)
- WEIGHT
Net With Stand: 7.32 kg (16.14 lbs)
Net Without Stand: 5.48 kg (12.08 lbs)
Gross With Stand: 9.76 kg (21.52 lbs)
- VIDEO INPUT
Frequency: Fh: 24~82kHz, Fv: 50~85Hz
Sync: H/V separated (TTL)
Analogue: RGB analog (75 ohms, 0.7 Vp-p)
- POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR® standards
- SECURITY
Kensington security port
- VESA MOUNT COMPLIANT
VESA FDMI 100X100mm
- ERGONOMICS
Tilt: -5°/+20°
