- DIMENSIONS
W x H x D mm: 440 x 383 x 195 (with stand)
440 x 304 x 62 (without stand)
520 x 460 x 142 (packaging)
- REGULATIONS
TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R, Hygienic (20 copies), UL, cUL, FCC-B (ICES), ICES-003B, NOM, SASO, ENERGY, ENERGY STAR, C-Tick, KTL/MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark, CCC, VCCI, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 32 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, DCR on/off, OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C–40°C
Humidity: 20%–90% (non-condensation)
- WEIGHT
Net: 4.0kg (with stand)
Gross: 5.1kg
- VIDEO INPUT
Frequency: Fh: 24–82kHz,
Fv: 50–75 Hz
Sync: H/V separate (TTL)
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
- POWER MANAGEMENT
TCO’03 and ENERGY STAR standards
- SECURITY
Kensington security port
- VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 20°
