- REGULATIONS
TCO'99, GS, Ergo, ISO 13406-2 (pixel failure class II), TUV-S/IRAM/UL-AR S Mark, Argentina TUV/S, UL, cUL, FCC-B, CB, CE, NOM, ICES-003, GOST-R, SASO, BSMI, CCC, ENERGY STAR®, PSB, C-TICK
- PACKAGE CONTENTS
LCD display, power cable, 15-pin VGA cable, audio cable, Quick Start Guide, ViewSonic Wizard CD (User Guide/drivers)
- AUDIO
Speaker: Integrated stereo speakers
- CONNECTOR
Analogue: 15-pin mini D-sub (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in
- POWER
Voltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: 32 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], down, up, select [2], mute
OSD: Auto image adjust, contrast, brightness, audio adjust, ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5000K, 5400K, user RGB), Information (resolution, H/V frequency, pixel clock, model number, serial number), Manual image adjust (H. size, H/V position, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 5°C – 35°C
Humidity: 20% – 80% (non-condensing)
- WEIGHT
Net With Stand: 4.5kg
Net Without Stand: 4.0kg
- VIDEO INPUT
Frequency: Fh: 30 – 82kHz, Fv: 50 – 85Hz
Sync: H/V separated (TTL)
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohms)
- POWER MANAGEMENT
Meets TCO'99 and ENERGY STAR® standards
- ERGONOMICS
Tilt: Down 5°, Up 20°
