- REGULATIONS
FCC class B, BMSI, UL1950, cUL, CE, C-Tick, CSA
- WARRANTY
Please see:
http://www.viewsoniceurope.com/UK/Support/warranty.htm
- AUDIO
Speaker: 2x 10-watt
Output: Audio output, 1x R/L (line level/variable)/1x subwoofer output
- POWER
Voltage: AC 90–240V (universal), 50–60Hz
Consumption: 185W (typ)
- CONTROLS
Basic: Menu, -, +, down, up, input, power
Picture: Brightness, contrast, colour, tint, sharpness, colour temp
(cool, normal user)
Set Up: OSD H/V position, OSD timeout, language, system reset
(firmware version info)
Audio: Volume, bass, treble balance, earphone toggle, DVI audio-toggle,
speaker, line out, subwoofer toggle, MTS select
TV: Antenna input, caption mode, auto scan, add/delete channel,
- OPERATING CONDITIONS
Temperature: 0–35ºC
Humidity: 20–90% (non-condensing)
- WEIGHT
Net: 860mm x 524mm x 207mm
- TELETEXT
Full 250 page Fastext Memory
- Video Output Resolution
1x RGB D-sub 15-pin
- Input
2 x Euro Scart (RGB, CVBS, SVHS, R/L audio)
1 x RCA component (YPbPr), 1 x R/L
1 x RCA component (YCbCr), 1 x R/L
1 x RGB D-sub 15pin, 1/8" stereo mini jack
1 x DVI-D (HDCP)
1 x CVBS, 1 x R/L audio
1 x RS232 service port - no user function
2 x TV / RF multi region dual tuners (PAL-I/B/G, SECAM-L)
