EP4602T

46“ digital sign board with interactive touch (170cm height)

Sales Enquiry

GALLERY

OVERVIEW

In-store "Way-Finding” is easy with ViewSonic’s new interactive ePoster display solution. With its drift free 4K x 4K touch interface and vivid screen resolution, retail messaging and image navigation is easily with the all-in-one EP4602T ePoster. Simple connect the output of your PC to the versatile input ports and common USB port for your touch interface and your application comes alive. ViewSonic’s ePoster display can easily be connected to a corporate network by adding a network media player. Security is achieved through the locking back cover.

SPECIFICATIONS

COLORS
Black
COMPATIBILITY
Photo Formats: JPEG
Video Formats: MPEG 1/2/3, H.264, Xvid 1.00–AVI, MP4
Audio Formats: WMA, MP3, M4A (AA CC )
DIMENSIONS
Physical With Stand: 27.80" x 66.93" x 17.72" (706mm x 1700mm x 450mm)

REGULATIONS
FCC, ICES 003, CE
PACKAGE CONTENTS
ePoster, power cord, remote control with batteries, key, Quick Start
Guide, User Manual and Software on CD
AUDIO
Speaker: 5W (x2)
CONNECTOR
Card Reader : 2GB Compact Flash
POWER
Consumption: 260W (max)
Save Mode (W): Off < 1W
Supply: 3.2–1.38 A @ 100–240VAC, 50/60Hz
DISPLAY
Contrast Ratio : 4000:1 (typ)
Brightness: 450 cd/m2 (typ)
Type: Diagonal: 46" (116.84 cm)
Resolution: 1920x1080 pixel resolution
Color Depth: Over 16.7M color (depending on video card used)
Response Time: 8ms (typ gray-to-gray)
Viewing Angles: Up and down 178º, left and right 178º (typ) @ CR>10
Touch: Touch Mode One point click, long press right click, double click, draw

Resoltuion 4096x4096 dots

Response Time 8ms

Supports OS Windows® 7/2000/XP/Vista

Interface USB 2.0 (full speed), USB 1.1 port HID compliant
WEIGHT
Gross: 286.60 lbs. (130 kg)
Net: 264.5 lbs. (120 kg)
OPERATING CONDITIONS
Humidity: 20–90% (non-condensing)
Temperature: 32–104º F (0–40º C)
WARRANTY
1-year with extended options available
CONNECTORS
HDMI, VGA, YPbPr, USB (x3), A/V, RJ45 Pigtail
STORAGE ENVIRONMENT
Humidity: 10–90% (non-condensing)
Temperature: -4–140º F (-20–60º C)
CONTENT MANAGEMENT
Operating System: MS Windows
Software: Signage Manager Express
