Budget-friendly, widescreen performance
ViewSonic’s 51 cm / 20" VA2013w LCD brings value to big, widescreen displays. This display doesn’t compromise on features with 1600x900 resolution for brilliant HD images. This stylish 51 cm / 20" LCD delivers extreme clarity, amazing color with 20,000:1 dynamic contrast ratio and fast ClearMotiv® 5ms video response. Benefit from greater productivity with the ability to view two fullsize documents side-by-side or work in multiple applications simultaneously on the widescreen display. Integrated speakers in a stylish, slim-bezel design provide multimedia enjoyment. Eco-mode conserves power and can extend backlight life. VA2013w fits seamlessly into any office décor. It’s great for desktop applications at home, school or in the office.SPECIFICATIONS
- COLORSBlack
- LCDContrast Ratio: 1000:1 (typ.) / 20000:1 dynamic
Viewing Angles: 170o (H), 160o (V) at 10:1 c/r, 170o (H) 170o (V) at 5:1 c/r
Brightness: 300 cd/m² (typ.)
Display Area: 443 x 249 (mm)
Optimum Resolution: 1600×900
Response Time: 5ms (typ.)
Light Source: 50,000 hrs (typ.)
Panel Surface: Anti-Glare, Hard coating (3H)
Pixel Pitch: 0.276mm(H) x 0.276mm(V)
Colour Support: 16.7 M (6-bits + Hi FRC)
Size: 50.80cm (20") wide Color TFT Active Matrix LCD 16:9 aspect ratio - COMPATIBILITYPC: VGA up to 1600×900 Non Interlaced
Mac®: Power Mac, up to 1600×900
- DIMENSIONSPhysical With Stand: 481 x 369 x 200 (mm), 18.94 x 14.51 x 7.86 (in)
Physical Without Stand: 481 x 288 x 64(mm), 18.94 x 11.32 x 2.52 (in) - REGULATIONSCB, TCO03,WEEE,ROHS, EAEPT, UL/cUL, FCC-B, IRAM, NOM, Energy Star, ERGO,CE, Ukraine, GOST-R+Hygienic ,SASO, BSMI, PSB, C-TICK, KCC, CCC
- PACKAGE CONTENTSLCD display, VGA cable, Power cable, Quick Start Guide, ViewSonic Wizard CD
- INPUTSync: Separate Sync
Analogue: RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Frequency: Fh: 24-82kHz, Fv: 50-75Hz - CONNECTORAnalogue: 1×15 pin mini D-sub
Power: Built-in power Adapter, 3-Pin plug - POWERVoltage: AC 100-240V (Universal); 50/60Hz(Switch)
Consumption: 46 (typ)
Eco Mode: optimize 30W (typ.) / conserve 23W (typ.)
Save mode: ≦1W - CONTROLSBasic: [1], [2], Power, Down[▼], Up[▲]
On View (PC mode): Auto Image Adjust
Contrast/Brightness
Audio adjust: Volume mute
Color Adjust: sRGB, 9300K, 7500K, 6500K, 5000K
User Color: [R, G, B]
Information
Manual Image Adjust: H/V position, horizontal size, fine tune, sharpness, dynamic contrast, aspect ratio, Eco mode, setup menu, language select, resolution notice, OSD Position, OSD Time Out, OSD Background, memory recall. - OPERATING CONDITIONSTemperature: 41°F - 95°F (5°C - 35°C)
Humidity: 20 - 80% (Non condensed) - WEIGHTNet: 4.12kg (9.08lbs)
Gross: 5.21kg (11.49lbs) - POWER MANAGEMENTTCO'03, ENERGY STAR
- ERGONOMICS20° ~ -5°
- VESA MOUNT COMPLIANTVESA 100mm x 100mm
