OVERVIEW

The ViewSonic CDX4652-L is a 46” (46’’ viewable) commercial LED display that features an ultra-narrow bezel less than 3mm wide. With an edge-to-edge width of only 5.6mm between combined displays, the CDX4652-L is perfect for digital signage and video wall applications that deliver seamless, high-impact messaging in commercial, hospitality, and transportation venues. With its Full HD 1080p resolution, 500-nit brightness, 3,500:1 high contrast ratio, SuperClear® image enhance technology and wide viewing angles, as well as dual 10W stereo speakers, the CDX4652-L delivers sharp, vivid images with incredible sound for superior multimedia performance. Integrated DVI-out and RS232-out ports, along with a RS232 pass-through function, support the installation, management and scheduling of video wall for up to 5x5 daisy-chained displays. In addition, versatile connectivity options including HDMI, DisplayPort, DVI, D-Sub, YPbPr, and CVBS inputs, offer convenient, one-time installation for a variety of high-definition devices. The ViewSonic CDX4652-L is a reliable and easy-to-maintain commercial display solution.

Ultra-Narrow Bezel Optimized for Video Walls

Deliver impactful video walls and customer-facing messaging with ViewSonic’s CDX4652-L commercial display. It features an ultra-narrow bezel of under 3mm that maximizes the visual impactful of your company’s messaging. With a 5.6mm edge-to-edge bezel between combined displays, the CDX4652-L can create stunning, near-seamless images when used in large video wall configurations.

5x5 DVI Daisy-Chain Support

With integrated DVI output, the CDX4652-L supports up to a 5x5 daisy-chain setup for multi-display installations. As only one of the displays needs to be connected to an image/content source, installation and maintenance costs are reduced. In addition, 1080p signal transmission is supported in daisy-chain configurations.

Energy-Saving LED Backlight

The CDX4652-L utilizes an energy-saving LED backlight that consumes 35% less power than conventional CCFL backlight displays. This provides for a lower overall cost of ownership, along with a higher ROI, making it a great long-term investment.

Full HD and 500 Nits for Superior True-Color Performance

ViewSonic’s CDX4652-L displays content in Full HD 1920x1080 resolution with 500-nit high brightness to deliver superior pixel-by-pixel true-colour performance. At this resolution and brightness, high-definition multimedia messaging can be seen crystal-clear with a more realistic viewing experience.

SuperClear® Image Enhancement Technology with wide viewing angles

SuperClear® Image Enhancement Technology delivers the best colour performance and extends display viewing angles to 178 degrees both horizontally and vertically. You can now experience accurate and vivid colours with consistent levels of brightness from all angles—whether looking at the screen from above, below, the front, or the side—with no colour distortion or decay.


Efficient, User-Friendly Content Scheduling & Settings

The ViewSonic CDX4652-L commercial display provides an efficient, user-friendly scheduling interface via the on-screen display (OSD). Setup features include time and date scheduling, repeat and shuffle settings, as well as content source settings for various inputs. The CDX4652-L also features an internal clock with 7-day scheduler, and PIP/POP (picture in picture) functionality.

RS232 Input and output for easier Management

RS232 in/out provides users with an easier maintenance solution for multi-display digital signage configurations. Now all maintenance can be done from one PC/ Notebook, allowing for the efficient updating of settings to all displays via the primary CDX4652-L display.

IR pass-through from one controller to multiple displays

Using the IR pass-through function, you can now create an infrared control chain where one controller is able to adjust the settings on multi-display video walls. By using a single remote controller, you can save time when optimizing your CDX4652-L displays with your latest campaign messaging.

Versatile Inputs and One-Time Configuration Settings

With a versatile selection of inputs, including HDMI, DVI, DisplayPort, CVBS, YPbPr (YCbCr) and VGA, the CDX4652-L commercial display enables you to easily connect and use a variety of digital equipment. Best of all, the one-time display installation and setup feature means your preferred source settings are never lost.

Portrait or Landscape Mountable

The CDX4652-L is VESA-compliant (400x200mm or 200x200mm) and can be mounted in either portrait or landscape orientation for greater display flexibility in a variety of settings.

Dual Stereo Speakers for Crystal-Clear Sound

With a pair of integrated 10W speakers, the CDX4652-L combines eye-catching multimedia content with high-quality sound effects—creating a lasting audio-visual impression on your target audience or demographic.

LAN control for Remote Content and Display Settings

The CDX4652-L has an integrated RJ45 connection that allows you to remotely set up and manage display content from a PC or laptop. You can also remotely turn the display on or off, or adjust the volume and other settings, via a user-friendly on-screen interface.

SPECIFICATIONS


  • LCD PANEL
    Panel Size: 46''
    Type/ Tech: TFT LCD Module with DLED Backlight
    Display Area (mm): 1018.08(H) x 572.67 (V)
    Aspect Ratio: 16:9
    Resolution: 1920x1080
    Colors: 16.7M
    Brightness: 500 nits (typ.)
    Contrast Ratio: 3500:1 Typ
    Response Time: 8ms
    Viewing Angles: H = 178, V = 178 typ.
    Backlight: LED
    Backlight Life: 50,000 Hours Typ
    Hardness: Haze 44% /3H (Anti-Glare)
  • INPUT
    HDMI: x1
    RGB / VGA: x1
    DisplayPort: x1
    DVI: x1
    Audio: x1
    CVBS: x1
    YPbPr: x1
    IR Pass Through: x1
    RS232: x1
