- Dimensions (mm)
Physique avec support: 407 x 375 x 210
Physique sans support: 407 x 293 x 63
Emballage (LxHxP): 456 x 420 x 156
- NORMES
GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R+Hygienic (3 copies), UL, cUL, FCC-B (ICES), ICES-003B, NOM, SASO, ENERGY, ENERGY STAR, C-Tick, MIC, BSMI, PSB, MPR II, VCCI, CCC, WEEE, RoHS
- CONTENU DE L'EMBALLAGE
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- CONNECTEURS
Analogique: 15-pin mini D-sub (detachable cable)
Alimentation: 3-pin AC plug (CEE22)
- Alimentation
Tension: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consommation: 25 watt (typ.), <1 watt in power save mode
- COMMANDES
De base: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution,
H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu
(language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- CONDITIONS D'EXPLOITATION
Température: 0°C – 40°C
Humidité: 10% – 80% (non-condensation)
- Poids
Net avec support: 3.2kg
Net sans support: 2.9kg
Brut: 4.0kg
- Entrée vidéo
Fréquence: Fh: 24–82kHz, Fv: 50–75 Hz
Synchronisation: H/V separated (TTL)
Analogique: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
- GESTION ALIMENTATION
Meets MPR II and ENERGY STAR standards
- SÉCURITÉ
Kensington security port
- MONTAGE MURAL
VESA FDMI 75mm x 75mm
- ERGONOMIE
Inclinaison: Down 5°, Up 20°
