| Projection System: | 0.48" WUXGA |
| Native Resolution: | 1920x1200 |
| Brightness: | 5000 ANSI Lumens |
| Contrast Ratio: | 3000000:1 |
| Display Colour: | 1.07 Billion Colours |
| Light Source Type: | Laser Phosphor system |
| Light Source Life (Normal): | up to 20000 |
| Lamp Watt: | Nichia 67W x2 |
| Lens: | F=1.83-1.86, f=9.6-9.4mm |
| Projection Offset: | 0% |
| Throw Ratio: | 0.81-0.89 |
| Optical Zoom: | 1.1X |
| Digital Zoom: | 0.8x-2.0x |
| Image Size: | 60"-200" |
| Throw Distance: | 1.04-3.83m (100"@1.74m) |
| Keystone: | H:+/-40° , V:+/-40° |
| Lens Shift V. Range: | Yes (+50%, -50%) |
| Lens Shift H. Range: | Yes (+23%, -23%) |
| Audible Noise (Normal): | 35dB |
| Audible Noise (Eco): | 28dB |
| Input Lag: | 16ms |
| Resolution Support: | VGA(640 x 480) to WUXGA(1920 x 1200) |
| HDTV Compatibility: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video Compatibility: | NTSC, PAL, SECAM |
| Horizontal Frequency: | 15K-102KHz |
| Vertical Scan Rate: | 23-120Hz |
| Computer in (share with component): | 1 |
| Composite: | 1 |
| S-Video: | 1 |
| HDMI: | 2 (HDMI 1.4a/HDCP1.4 x2) |
| Audio-in (3.5mm): | 1 |
| Audio-in (RCA R/L): | 1 |
| 3D VESA (Sync): | 1 |
| HDBaseT: | 1 |
| RJ45 Input: | 1 (LAN control) |
| Monitor out: | 1 |
| Audio out (3.5mm): | 1 |
| Speaker: | 10W x2 |
| USB Type A (Power): | 1 (5V/ 1.5A) (share with service) |
| 12V Trigger (3.5mm): | 1 (3.5mm) |
| RS232 (DB 9-pin male): | 1 |
| RJ45: | 1 |
| USB Type A (Services): | 1 (share with USB A Output) |
| Power Supply Voltage: | 100-240V+/- 10%, 50/60Hz (AC in) |
| Power Consumption: | Normal: 280W Standby: <0.5W |
| Operating Temperature: | 0~40℃ |
| Net Weight: | 6.6kg |
| Dimensions (WxDxH) with Adjustment Foot: | 405x305x145mm |
| OSD Language: | English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, total 23 languages |
| Power Cord: | 1 |
| VGA Cable: | 1 |
| Remote Control: | 1 (w/ laser pointer) |
| QSG: | 1 |
