Projector
LS860WU
Key Features
- 차세대 레이저 인광 기술, 20000시간 달하는 램프수명
- 투사비율이 0.81-0.89인 단초점 렌즈 장착
- 폭넓은 H/V 렌즈 시프트
- 360° 투사 & 90° 인물 모드
- HDBaseT 리시버 내장
Product Description
ViewSonic LS860WU is an advanced 5,000 ANSI Lumens WUXGA short throw installation projector. Adopting the 2nd generation laser phosphor technology, it offers high and consistent brightness for a reliable light source life of 20,000 hours. Short throw ratio, 1.1x optical zoom, wide lens shift, 360° projection and portrait mode together build up amazing flexibility to create an overwhelmingly immersive experience, especially ideal for blending projection applications in simulation/experience centers, restaurants and gyms. Adding on to that are the compact size and built-in HDBaseT, ensuring the cost-effectiveness desired.
Visit Us
- www.viewsonic.com
-
SPECIFICATION
Projection System: 0.48" WUXGA Native Resolution: 1920x1200 Brightness: 5000 ANSI Lumens Contrast Ratio: 3000000:1 Display Colour: 1.07 Billion Colours Light Source Type: Laser Phosphor system Light Source Life (Normal): up to 20000 Lamp Watt: Nichia 67W x2 Lens: F=1.83-1.86, f=9.6-9.4mm Projection Offset: 0% Throw Ratio: 0.81-0.89 Optical Zoom: 1.1X Digital Zoom: 0.8x-2.0x Image Size: 60"-200" Throw Distance: 1.04-3.83m
(100"@1.74m)Keystone: H:+/-40° , V:+/-40° Lens Shift V. Range: Yes (+50%, -50%) Lens Shift H. Range: Yes (+23%, -23%) Audible Noise (Normal): 35dB Audible Noise (Eco): 28dB Input Lag: 16ms Resolution Support: VGA(640 x 480) to WUXGA(1920 x 1200) HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p Video Compatibility: NTSC, PAL, SECAM Horizontal Frequency: 15K-102KHz Vertical Scan Rate: 23-120Hz -
INPUT
Computer in (share with component): 1 Composite: 1 S-Video: 1 HDMI: 2
(HDMI 1.4a/HDCP1.4 x2)Audio-in (3.5mm): 1 Audio-in (RCA R/L): 1 3D VESA (Sync): 1 HDBaseT: 1 RJ45 Input: 1
(LAN control) -
OUTPUT
Monitor out: 1 Audio out (3.5mm): 1 Speaker: 10W x2 USB Type A (Power): 1 (5V/ 1.5A)
(share with service)12V Trigger (3.5mm): 1 (3.5mm) -
CONTROL
RS232 (DB 9-pin male): 1 RJ45: 1 USB Type A (Services): 1 (share with USB A Output) -
OTHERS
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz
(AC in)Power Consumption: Normal: 280W
Standby: <0.5WOperating Temperature: 0~40℃ Net Weight: 6.6kg Dimensions (WxDxH) with Adjustment Foot: 405x305x145mm OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, total 23 languages -
STANDARD ACCESSORY
Power Cord: 1 VGA Cable: 1 Remote Control: 1
(w/ laser pointer)QSG: 1
