PJ-WPD-200
Features
Specifications
Downloads
PJ-WPD-200
USB Wireless Adapter
Sales Enquiry
gallery
GALLERY
OVERVIEW
The ViewSonic
®
PJ-WPD-200 USB wireless adapter provides added convenience and flexibility to your projection needs. With the PJ-WPD-200, you can wirelessly project from Windows
®
or Mac laptops, and you can use your Android™ or iOS devices to wirelessly stream content to a projector. Equipped with 2T2R MIMO, and support for up to 300Mbps, the PJ-WPD-200 delivers high-speed and robust data transmission via the IEEE 802.11b/g/n protocol. In addition, the portable and compact design of the PJ-WPD-200 provides an easy way for users to wirelessly connect their projectors. The PJ-WPD-200 is compatible with USB 2.0, most laptops, and select ViewSonic projectors equipped with ViewSync™ Advanced Connect™ Technology (ACT), as well as select ViewSonic PLED models.
SPECIFICATIONS
DATA TRANSFER RATE
maximum of 300M bps
MODULATION METHOD
BPSK/ QPSK/ 16-QAM / 64-QAM / DBPSK/ DQPSK/ CCK
FREQUENCY BAND
2.4GHz ISM Band
SPREAD SPECTRUM
IEEE 802.11b: DSSS (Direct Sequence Spread Spectrum) IEEE 802.11g/n:OFDM (Orthogonal Frequency Division M ultiplexing)
RF OUTPUT POWER (tolerance ± 2dBm)
13dBm@11n, 15dBm@11g, 17dBm@11b
OPERATION MODE
Ad hoc, Infrastructure
RECEIVER SENSITIVITY
11M bps -80dBm@8%,54M bps -70dBm@10%,300M bps -64dBm@10%
OPERATION RANGE
Indoor up to 100 meters, Outdoor up to 280 meters
LED
Blue
OS SUPPORT
Window XP/7/8, MAC
SECURITY
64 bit/128 bit WEP, TKIP, AES, WPA, WPA2
INTERFACE
USB 2.0
POWER
Consumption:
Transmit: 253 mA /Receive: 162 mA / Transmit+ Receive: 274 mA
OPERATING CONDITIONS
Temperature:
14°F to 140°F (-10°C to 60°C)
Humidity:
0% to 95% Non-Condensing
Altitude:
0 to + 13123 ft
DIMENSIONS (W x H x D)
Physical (inch / mm):
1.14 x 0.28 x 0.63/29 x 7 x 16
WEIGHT
Net (oz /g):
0.13 / 3.70
REGULATIONS
Standard:
Safety/EMC: FCC-B, CE, ErP, RoHS, WiFi: FCC-ID, CE R&TTE, NCC
What's in the box?
The Top Level Assembly shall consist of : 1. Wireless Presentation Dongle PJ-WPD-200 2. Quick User Manual
View full specs
SUPPORT & DOWNLOADS
Datasheets
PJ-WPD-200 Datasheet
User Guides
PJ-WPD-200 User Guide (English)
×
