OVERVIEW

ViewSonic’s new CDP4635 Full HD Commercial display features a FHD 1920x1080panel with 4000:1 contrast and Intel’s Open Pluggable Specification (OPS) for applications requiring an integrated media player. Additional features include versatile inputs – HDMI, DVI, VGA, S video and composite, YPbPr and built in 10W x 2 speakers. The CDP4635 will support up to a 5x5 display video wall with internal clock and scheduler. RS232 daisy chain and RJ45 are provided for automated remote control.

Production Description

Key Features

  • 1920x1080 resolution
  • Intel - OPS slot provides easy media player integration
  • Video Wall ready – up to 5x5
  • Adjustable bezel for easy touch panel integration
  • Internal speakers

SPECIFICATIONS


  • LCD
    Type: 46" color TFT active matrix, wide LCD
    Display Area: 40" horizontal x 22.5" vertical; 46" diagonal
    Optimum Resolution: 1920x1080, 530mm dot pitch
    Contrast Ratio: 4000:1 (typ)
    Viewing Angles: 178º horizontal, 178º vertical
    Response Time: 8ms
    Light Source: Long life, 50,000 hrs. (typ)
    Brightness: 400 cd/m2 (typ)
    Aspect Ratio: 16:9
    Panel Surface: Anti-glare, hard coating (3H)
  • INPUT
    TV: 480i, 480p, 720p, 1080i, 1080p
    Video Input: HDMI, DVI, component, VGA, S-Video, composite
    Video Output: VGA, component, DVI
    Control Input/Output: RS-232/RJ45
  • AUDIO
    Speakers: 2 x 10w
