CDE4802

Audio: x1 Earphone Out
SPDIF: x1
Remote Control Out: x1

Type A: x1 ( Support FAT32 & FAT16 / NTFS ( read only)

10W x 2

RGB PC/HDMI PC: Refer to timing table
CVBS: 480i,576i
YPbPr: 480i, 480p,720p, up to 1080p
HDMI: 480i, 480p,720p, up to 1080p
DVI: Up to 1920x1080 @60Hz

Physical- Top OSD: PICTURE: Picture Settings Picture Mode(Power Saving/Dynamic/Stander/Movie/User),
Screen Size ( Wide/Cinema/Zoom/Normal)
PC Settings
Color Temparature ( Normal/Warm/Cool)
Backlight (Medium/High/Low)
Advanced Picture Settings(Dynamic Contrast-Low/Medium/high/off; Film Mode-on/off; Noise Reduction-Low/Medium/high/off; MPEG Noise Reduction- low/Medium/high/off.
SOUND: Sound Setting( Standard/Soft/User/Dynamc),Analog Sound, Digital Sound, Digital Audio Output, Equalizer Setting.
PARENTAL: Lock Parent Control, V-CHIP,Change Password, Keypad Lock, Source Lock, System Lock.
SETUP: Closed Caption, Menu Language( English/French/Spanish/German/Portuguese), Clock, OSD Transparency, OSD Timer.
OTHERS: Blue Back, No Signal Power Off, No Operation Power Off, User Moniro, Audio Only, TV ID, All Reset.
Multimedia: PICTURE: JPEG, BMP, PNG
VIDEO: MPEG1, MPEG4/H.264, RM/ RMVB (1280*720@30p, Max.10Mbps) , MOV. MJPEG (640*480@30p Max.10Mbps) , DivX., FLV, VC-1 Decoder, WMA
AUDIO: WAV, MP3, M4A (AAC, PCM, MPEG1, AC3, COOKER, Vorbis)

Voltage: 100-240VAC +/- 10% 50/60Hz Wide Range
Consumption: 76W (typ), 95W (max)
< 0.5 W ("Off")

Wall Mount (VESA® ): 200 x 200

Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% @40°C non-condensing

Physical (inch / mm): 42.6x26.6x10.1 / 1082.4x676.1x255.6 (w/ stand)
42.6x24.7x3.4 / 1082.4x627.7x84.9 (w/o stand)
Packaging (inch / mm): 46.9 x 30.0x 2.6 / 1190 x 760x 165 (w/o Stand)

Net (lb / kg): 23.6 / 10.7 (w/o stand)
27.56 / 12.5 (with Stand)
Gross (lb / kg): 35.05 / 15.9

FCC, CE, CB, cTUVus or UL (by request), RoHS Mexico-UL CoC,
HDMI logo, Dolby Digital

1. CDE4800-L display 2. Remote Control with batteries 3. User manual wizard CD 4. Quick Start Guide 5. Power cable 6. Screw driver 7. (Optional) Glass Stand

*Actual content may differ from market to market
