Speed, simplicity and sound
Treat yourself to a master stroke of aesthetic design. The 19" ViewSonic VX912 impresses with its pure lines elegant simplicity – without sacrificing performance: HIGH BRIGHTNESS AND CONTRAST values deliver EXCELLENT IMAGE QUALITY and a response time of just 5ms lends films, games and DVDs excellent fluid motion. A set of stereo speakers are cleverly hidden within the casing and this model is additionally equipped with both an analogue and digital input. This high-tech monitor is just the shot for demanding home or business users. It’s not just a multimedia LCD. It’s a ViewSonic.
SPECIFICATIONS
- LCDType: 48cm / 19" TN colour TFT active matrix SXGA LCD
Contrast Ratio: 700:1 (typ.)
Viewing Angles: 150° horizontal, 135° vertical (at 10:1)
170° horizontal, 155° vertical (at 5:1)
Brightness: 300cd/m²
Display Area: 37.6cm horizontal x 30.1cm vertical, 48.3cm diagonal
Optimum Resolution: 1280 x 1024
Response Time: 5ms (off-on-off) (typ.)
Panel Surface: Anti-glare (3H)
Pixel Pitch: 37.6cm horizontal x 30.1cm vertical, 48.3cm diagonal
Colour Support: 16.2M colours (6-bit+2-bit FRC)
Pixel Clock: 135MHz - COMPATIBILITYPC: VGA up to 1280 x 1024 non-interlaced (max. 75Hz)
Mac®: Power Mac™ up to 1280 x 1024 non-interlaced (max. 75Hz) - DIMENSIONSW x H x D mm: 431 x 468 x 201 (with stand)
431 x 370 x 66 (without stand)
- REGULATIONSTCO’99, NEMKO/GS2, NEMKO/ERGO3, CE, CB, UL, cUL, FCC-B, ENERGY, NOM,
ISO13406-2 (pixel failure class II), GOST-R (+Hygienic), (SASO), PCBC, VCCI, BSMI,
CCC, (PSB), (C-TICK), Argentina-S, PSE, Green Mark - PACKAGE CONTENTSLCD Monitor, power cable, 15-pin VGA video cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) - WARRANTYPlease see: www.viewsoniceurope.com/UK/Support/warranty.htm
- INPUTSync: H/V separate (TTL), composite, sync on green
Digital: DVI-D (TMDS, 100 ohm)
Analogue: RGB analogue (0.7 Vp-p, 75 ohm)
Frequency: Fh: 30 – 82kHz, Fv: 50 – 85Hz - CONNECTORAnalogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Audio: 3.5mm stereo audio line-in
Power: 3-pin (CEE22) - POWERVoltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: 35 watt (typ.), <1 watt in power save mode - CONTROLSBasic: Power on/off, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), colour adjust
(sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency,
pixel clock, model number, serial number, website), manual image adjust (H/V
position, H size, fine tune, sharpness), setup menu (language, resolution notice,
OSD position, OSD timeout, OSD background), OSD/power lock, memory recall - OPERATING CONDITIONSTemperature: 0°C to 40°C
Humidity: 10% to 90% (non-condensation) - WEIGHTNet: 6.7kg (with stand), 5.3kg (without stand)
- POWER MANAGEMENTMeets TCO’99 and ENERGY standards
- ERGONOMICS35 watt (typ.), <1 watt in power save mode
- SECURITYKensington® security port
- VESA MOUNT COMPLIANTVESA FDMI 100mm x 100mm
- AUDIOSpeakers: 2 x 1 watt
