Captivating view with intense speed.
ViewSonic has broken the boundaries of XTREME PERFORMANCE WITH AN ASTOUNDING, INDUSTRY-LEADING 3MS RESPONSE TIME with smooth broadcast-quality and full-motion video. The VX724, 17" XTREME LCD display combines innovative Dynamic Structure™ and Amplified Impulse™ technologies to replace blurs and ghosts with pure, vibrant motion. Features like these are CAPTIVATING IN GRAPHIC-INTENSIVE APPLICATIONS LIKE GAMES AND VIDEOS. OptiSync® technology further enhances this display’s appeal by enabling connections to multiple digital and analogue video sources. The VX724 also features 1280 x 1024 native resolution, high brightness and contrast ratios and wide viewing angles. Choose high performance features in an elegant package with the 3ms VX724 display.
SPECIFICATIONS
- LCDType: 43cm / 17" TN-Colour TFT Active Matrix SXGA LCD
Contrast Ratio: 135MHz
Viewing Angles: 140° horizontal, 130° vertical @ 10:1
160° horizontal, 160° vertical @ 5:1
Brightness: 300cd/m² (typ.)
Display Area: 338mm horizontal x 270mm vertical; 43.2cm diagonal
Optimum Resolution: 1280 x 1024
Response Time: 3ms (grey-to-grey); 5.4ms (on-off-on) (typ.)
Light Source: Long life, 40,000hrs. (typ.)
Panel Surface: Anti-glare
Pixel Pitch: 0,264mm
Colour Support: 16.2M colours (6-bit + 2-bit FRC)
Pixel Clock: 135MHz - COMPATIBILITYPC: VGA up to 1280 x 1024 (@ max. 75Hz non-interlaced)
Mac®: Power Mac™ G3/G4/G5 1280 x 1024 (@ max. 75Hz) - DIMENSIONSW x H x D mm: 388 x 438 x 176 (with stand)
388 x 332 x 62 (without stand)
- REGULATIONSTCO’99, CE, CB, NEMKO/GS2, NEMKO ERGO3, ISO13406-2
(pixel failure class II), UL, cUL, FCC-B, ENERGY, NOM, GOST-R + 20
original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB,
C-TICK, Argentina-S, PSE (power adapter), Green Mark - PACKAGE CONTENTSLCD display, power cable, 15-pin VGA video cable, DVI cable,
Quick Start Guide, ViewSonic Wizard CD - WARRANTYPlease see:
www.viewsoniceurope.com/UK/Support/warranty.htm - INPUTSync: H/V separated (TTL), composite, sync-on-green
Frequency: Fh: 30-82kHz, Fv: 50-75Hz
Video: RGB analogue (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms) - CONNECTORAnalogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Power: 3-pin AC plug, (CEE22) - POWERVoltage: AC 100–240V, 50–60Hz (auto switch), internal power supply
Consumption: < 32W (typ); ≤ 1 watt in power save mode - CONTROLSPhysical: Down 5°, Up 20°
Main Menu: Auto image adjust, brightness, contrast, input select [analogue,
digital], ViewMatch® colour adjust [sRGB, 9300K, 6500K-default,
5400K, user colour - RGB], information [resolution, H. frequency,
V. frequency, pixel clock, model number, serial number], manual
image adjust [H. size, H./V. position, fine tune, sharpness], setup
menu [language (English, French, German, Italian, Spanish, Finnish,
Japanese, Traditional Chinese, Simplified Chinese), resolution
notice, OSD position, OSD timeout, OSD background], memory
recall, OSD lock, power lock - WEIGHTNet: 5.0kg (with stand)
- POWER MANAGEMENTMeets TCO’99, Energy and ENERGY STAR standards
- ERGONOMICSTilt: Down 5°, Up 20°
- OPERATING CONDITIONSHumidity: 10% to 90% (non-condensation)
Temperature: 0°C to 40°C
