OVERVIEW
For big performance and even bigger productivity you need a big screen. The ViewSonic VG2230wm features large widescreen multimedia performance for a unique desktop experience. The 56 cm / 22" WIDESCREEN display allows you to view two documents side-by-side or work in two applications simultaneously and the 360° SWIVEL base allows you to share your view with co-workers. The 280cd/m² brightness and high 700:1 contrast ratio produce bright, crisp, detailed images whilst analogue and digital inputs ensure versatile connectivity options. Graphics professionals love the FAST 5MS VIDEO RESPONSE TIME that delivers blur-free, full motion video and crystal clear images. And with ERGONOMIC HEIGHT ADJUSTMENT and tilt, you’ll work comfortably for hours. The VG2230wm widescreen multimedia LCD delivers a complete visual experience to your desktop.Big screen, big performance
It’s not just a large digital widescreen LCD. It’s a ViewSonic.
REVIEWS
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“"Le plus bel écran du test. Son pied réglable en hauteur lui confère une ergonomie sans faille."”
“9/10 - "Une ergonomie irréprochable."”
“"L'ergonomie du pied, la qualité d'image en définition nominale et les deux interfaces nous ont beaucoup plu."”
“"Des images d'excellente qualité et un équipement complet."”
“Personal Computer World”
“ViewSonics testdeltager leverer en særdeles fornuftig billedkvalitet, der er tilstrækkelig til at almindelige brugere både kan pløkke skurke i 3D-skydespil og arbejde seriøst med billedbehandling. At skærmen har højdejustering indbygget i sokkelen, er blot med til at cementere pladsen i testens top.”
“"Il vincitore indiscusso di questo confronto, il ViewSonic VG2230wm offre immagini di eccelente qualità ed è comodisimo da usare."”
“"Il est bon partout. Difficile de trouver un défaut à cet écran."”
“"Bra funktioner, ergonomisk, bra kvalitetsintryck."”
“" ... le VG2230wm offre à la fois qualité d'affichage, confort d'utilisation et design."”
“ViewSonic's 22-inch wide screen desktop display, the VG2230wm has been named eWEEK's Channel Product of the Year with a score of 3.7. ViewSonic's strong channel presence and familiarity among solution providers were contributing factors in the award selection.”
“"Als Testsieger ist der VG2230wm von ViewSonic hervor gegangen. Er verfügt in der Summer über ordentliche Displayeigenschaften, punktet mit der besten Ausstattung und obendrauf gibt es noch dans eleganteste Display-Design."”
“Ranked 4th best 20- or 22-inch model (out of 5); "This 22-inch display is thoughtfully designed, and its graphics and text reproductions are easy on the eyes." - Greg Adler”
SPECIFICATIONS
- COLORSBlack
- LCDType: 56 cm / 22" Wide TN colour TFT active matrix WSXGA+ LCD
Contrast Ratio: 700:1 (typ.)
Viewing Angles: 170° horizontal, 160° vertical (at 10:1)
170° horizontal, 170° vertical (at 5:1)
Brightness: 280cd/m² (typ.)
Display Area: 47.6cm horizontal x 29.8cm vertical, 55.9cm diagonal
Optimum Resolution: 1680 x 1050@60Hz
Response Time: 5ms (off-on-off) (typ.)
Light Source: Long life, 60000 hrs. (typ.)
Panel Surface: Anti-glare
Pixel Pitch: 0.282mm
Colour Support: 16.7M colours (6-bit + 2-bit FRC)
Pixel Clock: 165MHz - COMPATIBILITYPC: VGA up to 1680 x 1050 non-interlaced
Mac®: Power Mac™ G3/G4/G5 up to 1680 x 1050 non-interlaced
- DIMENSIONSPhysical With Stand: 519 x 436-571 x 250
Physical Without Stand: 519 x 392 x 60
W x H x D mm: 570 x 530 x 300 - REGULATIONSTCO'03, GS, ERGO, ISO 13406-2 (pixel failure class II), CB, CE, GOST-R, UL, CUL, FCC-B, ICES-003, NOM, SASO, ENERGY STAR®, C-Tick, MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark, CCC, WEEE, RoHS
- PACKAGE CONTENTSLCD Monitor, power cable, 15-pin VGA video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
(multi-language) - AUDIOSpeaker: 2 x 2 watt integrated stereo speakers
- CONNECTORAnalogue: 15-pin mini D-sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in - POWERVoltage: AC 100– 240V, 50/60Hz (auto switch), internal power supply
Consumption: 43 watt (typ.), <1 watt in power save mode - CONTROLSBasic: Power, menu [1], up, down, select [2], mute, volume up/down
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K), information (resolution, H/V frequency, pixel clock, model number, serial number), audio adjust (volume, mute), manual image adjust (H/V position, fine tune, sharpness), setup menu (language, resolution
notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall - OPERATING CONDITIONSTemperature: 0°C – 40°C
Humidity: 10% – 90% (non-condensation) - WEIGHTNet With Stand: 6.6kg
Gross: 8.6kg - VIDEO INPUTFrequency: Fh: 24~82kHz, Fv: 50~85Hz
Sync: H/V separated (TTL)
Analogue: RGB analogue (0.7 Vp-p , 75 ohms)
Digital: DVI-D (TMDS, 100 ohm) - POWER MANAGEMENTMeets TCO’03 and ENERGY STAR® standards
- SECURITYKensington® security port
- VESA MOUNT COMPLIANTVESA FDMI 100mm x 100mm
- ERGONOMICSTilt: Down 5°, Up 20°
Swivel: 360° swivel base
Height Adjustment: 0~ 135mm
