- REGULATIONS
TCO´99, TÜV/GS, TÜV/Ergo, TÜV-S, ISO13406-2 (class 2), UL, c-UL,
IC-B, CB Report, CE, FCC-B, BSMI, VCCI, PSB, PCBC, EPA, NOM, CTICK,
GOST-R, PCT, CCC, EnergyStar, ENERGY, Taiwan Green mark
- CONNECTOR
Signal: 15-pin mini D-sub, attached cable
Power: 3-pin AC plug
- POWER
Voltage: AC 100–240V, 50–60Hz (internal power supply)
Consumption: <35W (typ); ≤ 1 watt in power save mode
- CONTROLS
Basic: Power (Soft), [1], [Down], [Up], [2]
OSD: Auto Image Adjust, Contrast, Brightness, Colour Adjust [sRGB,
9300K, 6500K (default), 5400K, R, G, B], Information [Mode, Model
Number, Serial Number, Website], Manual Image Adjust [H. Size,
H. Position, V. Position, Fine Tune, Sharpness, Setup Menu Language
(English, French, German, Italian, Spanish, Finnish, Japanese,
Simplified and Traditional Chinese), Resolution Notice, OSD
Position, OSD Timeout, OSD Background], Memory Recall
- OPERATING CONDITIONS
Temperature: 0–40°C
Humidity: 10–90% (non-condensing)
- WEIGHT
Net: 4.1 kg
- VIDEO INPUT
Frequency: Fh: 30~80kHz, Fv: 50~75Hz
Sync: H/V separated (TTL)
Analogue: RGB Analogue (75 ohms, 0.7 Vp-p)
- POWER MANAGEMENT
Meets TCO'99, ENERGY and Energy Star standards.
