- REGULATIONS
TCO’03, CE, CB, GS, Ergo, ISO13406-2 (pixel failure class II), UL/cUL, ENERGY STAR, FCC-B, NOM, GOST-R, BSMI, CCC, (PSB), (C-TICK), Green Mark, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
- AUDIO
Speaker: 2 x 1 watt integrated invisible stereo speakers
- CONNECTOR
Analogue: 15-pin mini D-Sub (attached cable)
Power: 3-pin AC plug (CEE22)
Audio (input/output): 3.5mm stereo audio line-in
- POWER
Voltage: AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Consumption: <35 watt (max.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language [English, Finnish, French, German, Italian, Japanese, Spanish, Simplified Chinese, Traditional Chinese], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0°C – 40°C
Humidity: 10% – 90% (non-condensing)
- WEIGHT
Net With Stand: 4.6kg
Gross: 5.8kg
- VIDEO INPUT
Frequency: Fh: 30 – 82kHz, Fv: 50 – 85Hz
Sync: H/V separated (TTL)
Analogue: RGB analogue (0.7 Vp-p, 75 ohm)
- POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 20°
