Short distance - big presentation
The powerful PJD5351 sets the stage for a new generation of versatile projectors equipped with BrilliantColor™ technology and an extreme short-throw ratio – producing a 152cm / 60" image at a distance of only 1.1m away. With its short-throw lens, the PJD5351 saves space by allowing you to place it at the front of your table and still display large, crisp images. Weighing in at just 2.5kg with 2500 ANSI lumens and a 2400:1 contrast ratio (with DCR), it's easy to give multimedia lessons in the classroom or dynamic presentations in the boardroom. Multiple preset presentation modes, an increased 40 degree digital vertical keystone correction and digital zoom ensure the best possible image regardless of location. With up to 4000 hours of lamp life*, low-cost replacement lamps, filter-less design and a non-degrading DLP® light engine, the PJD5351 has one of the lowest total cost of ownership ratios in the industry.
SPECIFICATIONS
- COLORSBlack
- COMPATIBILITYPC: VGA to SXGA
Mac®: Up to 1280×1024 (may require Mac Adapter) - DIMENSIONSPhysical (WxHxD): 264 × 96.4 × 225 (mm) / 10.4 × 3.8 × 8.86 (inch)
W x H x D mm: 380 × 324 × 191 (mm) / 14.9 × 12.8 × 7.5 (inch)
- REGULATIONSCB, ROHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM (Argentina), NOMPSB, C-tick, EK, CE, TUV/GS, GOST-R, Hygienic, SASO UKrSEPRO, CCC
- PACKAGE CONTENTSViewSonic projector, power cable, VGA cable, remote control with batteries, lens cap, Quick Start Guide, ViewSonic Wizard CD (with User Guide), soft case
- WARRANTY3-year limited warranty on parts, 1-year limited warranty on lamp
- AUDIOSpeaker: 5W×1
- INPUT SIGNALFrequency: Fh: 30-100 KHz, Fv: 50-87 Hz
Computer and Video: NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SD 480i and 576i (24fps, 25fps and 30fps), ED 480p and 576p (24fps, 25fps and 30fps), HD 720p, 1080i (24fps, 25pfs and 30fps) - CONNECTORS-Video Input: 1 × 4-pin mini-DIN
Control: 1×RS-232 (8 Pin Mini-Din)
RGB (input/output): 2 × 15-pin mini D-sub / 1 × 15-pin mini D-sub
Audio (input/output): 1 × 3.5mm mini jack / 1 × 3.5mm mini jack
Component: 2 × 15-in mini -D-Sub (sharer with RGB)
Composite Input: 1 × RCA jack - POWERVoltage: 90~240VAC (Auto Switching), 50/60Hz (universal)
Consumption: 242W (Typical) / <5W (Stand-by mode) - CONTROLSOSD: Display: Screen color, aspect ratio, keystone, position, phase, H. size, digital zoom
Picture: Preset mode: brightest, standard (Video) ,daylight, ViewMatch (PC), cinema, user 1/user 2, brightness, contrast, color, tint, sharpness, BrilliantColorTM, color temp., save settings)
Source: Quick auto search
System setting (Basic): Language , projector position, auto power off, blank timer, panel key lock, timer controller, splash screen
System setting (Advanced): Quick cooling, high altitude mode, DCR, active VGA out, audio settings, menu settings, closed caption, lamp settings, security setting, reset all settings
Information: Current system status (source, preset mode, resolution, color system, equivalent lamp hour)
Keypad: Standby/On, input, menu - OPERATING CONDITIONSTemperature: 0ºC-40ºC (32ºF-104ºF)
Humidity: 10% - 90% (non-condensing)
Altitude: 0~1,800m (6000ft), operational up to 3,048m (10000ft) - WEIGHTNet: 2.5 kg (5.5lb)
- DISPLAYContrast Ratio : 2400:1 (with DCR)
Display size: 1.0m - 4.6m / 40"-180"
Aspect Ratio: 4:3 (native) & 16:9
Throw Distance: 0.75 - 3.5m
Throw Ratio: 0.9:1
Brightness: 2500 Lumens
Color Gamut: 85 % NTSC 1931 CIE
Lamp life ( Normal / Eco / Dynamic Eco ): 3000 / 4000 hours*
Type: 1.4 cm / 0.55" Digital Micromirror Device (DLP™)
Resolution: XGA 1024x768 (Native) / SXGA 1280×1024 (compressed)
Keystone: Vertical digital keystone correction: +/- 40 degrees
Lamp: 189 watt
Lens: Fixed len / Digital zoom / Manual focus - NOISE LEVELNormal: 30dB
Eco-mode: 26dB - LANGUAGEEnglish, French , German, Italian, Spanish, Russian, Traditional Chinese, Simplified Chinese, Japanese, Korean, Swedish, Dutch, Turkish, Czech, Portuguese, Thai, Polish, Finnish
