Impressive HDTV wide-screen home entertainment
Enjoy more detail, more colour and more depth with the new ViewSonic N2600w 26" high-definition LCD TV. This native 16:9 widescreen display combines a stylish, thin design with the latest video processing electronics for unforgettable entertainment encounters. Ultra-fast response times ensure crisp, vivid images no matter if watching thrilling videos or playing high-speed games. Full digital performance is assured thanks to the HDMI (HDCP compliant) input which provides both high compatibility and the best uncompressed connection for optimal screen depictions. With the picture-in-picture (PIP) and picture-by-picture (PBP) function, the N2600w also lets you watch a movie while surfing the internet or track a second video source. SRS virtual surround technology and two powerful stereo speakers complete your entertainment experience. This stylish LCD TV is your perfect choice for watching thrilling home TV.
SPECIFICATIONS
- LCDType: 66cm / 26" PMVA colour TFT active matrix, wide 1366 x 768
Contrast Ratio: 800:1 (typ.)
Viewing Angles: 170° horizontal, 170° vertical (at 10:1)
Display Area: 55.8cm (horizontal) x 32.4cm (vertical), 66cm diagonal
Response Time: 8ms (grey-to-grey)
Aspect Ratio: 8ms (grey-to-grey)
Panel Surface: Anti-glare
Brightness: 500cd/m2 (typ.) - COMPATIBILITYPC: Compatible from VGA up to 1360 x 768, 1360 x 768 @ 60Hz preferred
Mac®: Power Mac™ up to 1152 x 864 @ 75Hz - DIMENSIONSW x H x D mm: 688 x 541 x 245 (with base)
- REGULATIONS19kg (with base)
- PACKAGE CONTENTSLCD TV, power cables (Europe [Schuko]/UK), remote control, batteries,
quick start guide, user guide (multi-language), RF cable - WARRANTYPlease see:
www.viewsoniceurope.com/UK/Support/warranty.htm - CONNECTORDigital: HDMI (HDCP) with RCA Audio L/R In for DVI source
Audio Out: RCA Audio L/R
Power: 3-pin plug (ICE-C5)
S-Video: 1 x 4-pin mini DIN jack with RCA Audio L/R
Headphone: 11 x 3.5mm mini stereo jack
SCART: 2 x SCART2 (SCART1 [RGB In, S-video In, CVBS In/Out, Audio In/Out],
SCART2 [S-video In, CVBS In/Out, Audio In/Out])
Tuner: 1 x Coax RF (PAL/SECAM)
PC: 1 x 15-pin mini D-sub with 3.5mm mini stereo jack Audio L/R
Composite Video: 1 x RCA (CVBS) with RCA Audio L/R
Component Video: 1 x RCA set (YPbPr/YCbCr) with RCA Audio L/R - POWERVoltage: AC 90 – 240V, 50/60Hz (auto switch), internal, fanless power supply
Consumption: 180 watt (typ.), < 3 Watt in power save mode - CONTROLSBasic: Power, menu, source, channel up/down, volume up/down, main power
OSD: Picture Menu (contrast, brightness, tint, saturation, sharpness, colour
temperature [normal, warm, cold], aspect ratio [16:9, zoom, 14:9, 4:3,
panorama], picture mode [standard, movie, vivid, user]), Sound Menu
(audio source [main, sub], bass, treble, balance, NICAM [stereo, mono,
SAP]), TV channel menu (cur. Channel, channel name, frequency,
add/delete channel, system [cable, antenna], country, channel auto
search, TV reset), Option/PIP Menu (sleep timer, PIP [sub source, PIP size,
PIP H/V position, border colour, swap main/sub]), PC Menu (contrast,
brightness, H/V position, H size, fine tune, colour mode [colour temperature,
User-RGB], auto adjust), OSD Menu (language, OSD H/V
position, OSD timeout, OSD background, status information, memory
recall), power lock, OSD lock） - OPERATING CONDITIONSTemperature: 0 °C to 40 °C
Humidity: 10 % to 90 % (non condensation) - WEIGHTNet: 19kg (with base)
- VESA MOUNT COMPLIANTVESA® FPMPMI 200mm x 100mm M4 screws
- ERGONOMICSTilt: Down 5°, Up 10°
- TELETEXTYes (250 pages)
- VIDEO INPUTPAL, SECAM, NTSC3, SD (480i/p, 576i/p), HD (720p, 1080i)
- AUDIOSpeakers: 2 x 5-watts SRS audio enhancement technology (detachable)
