OVERVIEW
ViewSonic’s EP2203r is a 22” Full HD 1080p LED ePoster that delivers brilliant and crystal clear image quality from a sleek and slim profile. The premium design and slim profile allows it to be the perfect wall mount for informational and promotional applications in any setting, while the USB ports offer quick access to a wide range of formats for convenient content management.1.1920x1080 LCD panel with LED backlight
2.Brightness up to 250 nits and contrast ratio up to 3,000:1 for Excellent Color Image
3.Embedded media player supports photos, music and videos in high definition
4.Great compatibility for versatile advertisement content
5.Tempered glass cover provides 1K level impact resistance for protecting panel and ID design
6.Easy to upload playlist via USB
7.HDMI and VGA port offers great flexibility in connection
8.Built-in 2W+2W speaker
9.Ultra Slim design
SPECIFICATIONS
- COLORSBlack
- LCDType: 21.5" color TFT active matrix, wide LCD
Contrast Ratio: 3,000:1
Viewing Angles: 85° (H) / 80° (V)
Brightness: Internal: 250 nits / External: 220 nits
Display Area: 476.64 (H) x 268.11 (V)
Optimum Resolution: 1920 x 1080
Response Time: 25 ms
Aspect Ratio: 16:9
Panel Surface: Anti-glare, hard coating (3H) - DIMENSIONSPhysical (mm): 585.6 x 378.6 x 33.7
Physical (in): 23.06” x 14.91” x 1.33”
- PACKAGE CONTENTSPower Cable *1, Remote Control *1, Quick Start Guide *1, User Manual CD Wizard *1
- CONNECTORLAN: RJ45 *1
Power: 2 pin plug
Video In: VGA (D-Sub) *1
HDMI (1.3) *1
USB: 2.0 *2 - POWERVoltage: AC 100 - 240V (Universal) , 50 - 60Hz
- CONTROLSSet Up: Language, Clock Display, Scrolling Text, USB Port,
Return To Factory Settings. - WEIGHTGross: 22.05 lb. (10 Kg)
Net: 17.64 lb. (8 Kg) - OPERATING CONDITIONSHumidity: 20% ~ 90% (non-condensation)
Temperature: 32°F~122°F (0 ~ 50°C) - InputSupported Image H.264 TBD
Decoding Format
MPEG 1 TBD
MPEG 2 TBD
MPEG 4 - XVID TBD
JPEG TBD - AUDIO OUTSpeakers: 2W x2
- ControlsSystem Settings: Language, Clock Display, Scrolling Text, USB Port,Return To Factory Settings.
Playback Control: Storage Priority, Playback Mode, Play Time.
Date & Time: Year, Month, Day, Hour, Minute, Update Date & Time
On / Off Timer: Timer Mode, Daily, Sunday~Saturday
Local ID: ID, Save
Screen Mode: Vertical, Horizontal, Save and Reboot
File Management: Information, Format
Source: HDMI, VGA, Digital Signage
System Setting: OSD Language, Reset
Image: Brightness, Contrast, Saturation, Color Temp
PC Setting: Auto Adjust, H Position, V Position, Phase, Clock
