OVERVIEW
With the advanced 3LCD projection specification, the color and brightnessare more natural and purer, satisfying every requirement of experts’ bestcreative performances.Integrating the advanced Active-IRIS, it provides the high contrast of3500:1. Images with high brightness or darker scenes will be vividlyrepresented with the solidest and sharpest effects. XGA resolution fullyconveys various contents of high quality images. With the broader 1.5~2.5throw ratio, Pro9500 satisfies the spatial requirements of large scalemeetings and conferences. The specific Perfect Fit double projection isavailable for broad and bright briefing spaces. With the technology ofLens Shift, the single image can be projected by two Pro9500s at thesame time. The brightness will be improved to surprising 10,000 lumens. Itbrings the unprecedented bright vision for briefings.
The professional projection is enhanced by the intelligent network control.Through regional network or internet, the innovative LiveViewer networkdisplaying makes it possible to link single computer with several projectorsin a company or in the campus for network projection and broadcasting.
The HDMI digital interface is available for linking multiple high qualityvideo outputs. USB interface is supported at the same time so thecomputer images can be displayed through USB ports. Without linking tothe USB thumb-drive of the computer, the contents preserved in USBdevices will be projected in an easier way for briefings.
With its comprehensive advanced functions, Pro9500 will create a professionalvision for intelligent projection!
SPECIFICATIONS
- DisplayType: 0.63" inches (x3) Poly-Si TFT, 3 LCD Panels
Resolution: 1024x768
Pixel Format: 0x0
Lens: 1.7X
Size: 30 - 300 inch
Throw Distance: 0.9m - 9.1m
Lamp: 245 watt
Brightness: 5000 ANSI Lumens
Contrast Ratio: 3500:1
Keystone Correction: Vertical +/- 30 degrees - AudioSpeakers: 8 watt x 2
- Input SignalVideo: NTSC M (3.58MHz), 4.43MHz, PAL (B, D, G, H, I, M, N), SECAM (B, D, G, K, K1, L), 480i and 576i, 480p and 576p, 720p and 1080i and 1080p (for HDMI only)
Frequency: Fh: 31-106KHz; Fv: 56-120Hz
- CompatibilityPC: VGA to UXGA
Mac: Up to 1600×1200 (may require Mac Adapter) - ConnectorRGB Input: Input:1×15-pin mini D-sub
RGB Output: 1×15-pin mini D-sub
Composite Video: 1×RCA jack
S Video: 1×4-pin mini-DIN
Component Video: RCA-3 (x1 Set)
Digital: HDMI 1.3 x1
Audio: 3.5mm Mini-Mono Jack (x1) RCA (L/R) jack (x1) / Microphone IN 3.5mm Mini-Mono Jack (x1)
Control: 1×RS-232 (9 Pin D-Sub)
USB: Type B (x1) for USB display and mouse control Type A (x1) for PCLess presentation - PowerVoltage: 100~240VAC(Auto Switching), 50/60Hz (universal)
Consumption: 420W (Typical) / <0.5W - Operating ConditionsTemperature: 5ºC-35ºC (41ºF-95ºF)
Humidity: 10%-85% (non-condensing) - DimensionsPhysical: 401mm (width) x 308mm (height) x 103mm (depth)
- WeightNet: 4.7 kg
- RegulationsEN61000-3-3, EN55022, EN55024(EMC directive) ; EN60950-1 (Low
voltage directive); WEEE, RoHS, ErP,
C-Tick (Australia / New Zealand), NOM
