- REGULATIONS
TCO’03, TÜV/GS, TÜV/Ergo, ISO13406-2 (pixel failure class II), CE, CB, GOST-R, PSB, ENERGY STAR ,YCO03, UL/cUL, FCC-B, ICES 003, NOM, Argentina-TÜV/S, SASO, BSMI, C-Tick, MIC, CCC, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, D-sub video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Audio: 3.5mm stereo audio line-in
Power: 3-pin AC plug (CEE22)
- POWER
Voltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 39 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select [2], mute
OSD: Auto image adjust, contrast, brightness, input select (D-sub, audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 5°C–35°C
Humidity: 20%–80% (non-condensation)
- WEIGHT
Net: 5.2kg (with stand)
4.3kg (without stand)
Gross: 6.8kg (with stand)
- VIDEO INPUT
Frequency: Fh: 30–82kHz, Fv: 56–76Hz
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Sync: H/V separate (TTL)
- POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR® standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 20° (90° for wall mount)
- AUDIO
Speakers: 2 x 1.5 watt integrated stereo speakers
