| Display Area: | 344.232 (W)X195.538 (H) mm |
| Optimum Resolution: | 1366 x 768, 16:9 |
| Brightness: | 250 cd/m2 |
| Contrast Ratio: | 1000 : 1 |
| Viewing Angles: | 130°(V) / 90° (H) |
| Backlight: | LED Light-Bar |
| Surface Treatment: | 8H tempered glass |
| Frequency: | Horizontal:30-48kHz, Vertical:56-70Hz |
| Technology: | Electromagnetic Resonance |
| Touch Pen: | Battery-Free |
| Writing Response: | 200 PPS (point per second) |
| Pressure Level: | 2048 Levels |
| Digitizer Resolution: | 5080 LPI |
| Accuracy: | ± 0.5mm (center), ± 1 mm (edge) |
| Detectable Height: | 5 - 10mm above glass |
| PC: | Windows XP, Windows 7, Windows 8 |
| Power: | Share with USB |
| Video: | USB2.0 |
| USB: | x 1 |
| Tilt: | 5°, 15° |
| Voltage: | 12V / 2A |
| Consumption: | 6.5 W |
| Temperature: | 32°F to 104°F (0°C to 40°C) |
| Humidity: | 20% - 80%(Max), Non-Condensation |
| Physical (in / mm): | 15.35” x 11.41” x 0.88” inch 390 x 290 x 22.35 mm |
| Box (in / mm): | 17.87” x 14.76” x 5.11” inch 454 x 375 x130 mm |
| Net (lb / kg): | 1.86 kg |
| Gross (lb / kg): | 2.36 kg |
| CCC 1st level, CEL, CECP |
| 1. Pen Display x1 2. Quick Star Guide x1 3. Driver CD x1 4. USB 2.0 Y-cable x1 5. Replacement tool of Pen tip x1 6. Pen x1 7. Pen tip x3 8. Warranty card x1(VSCN only) 9. Pen rope x1 10. User Guide x1 (e-file) *Actual content may differ from market to market |
