VX2260wm

56cm / 22" (21.5 viewable) 16:9 WIDESCREEN LCD WITH FULL HD 1080p RESOLUTION

Sales Enquiry

GALLERY

OVERVIEW

Optimize your desktop experience with ViewSonic’s full HD 1080p 56cm / 22" (21.5” viewable) VX2260wm widescreen LCD. Encased in a glossy black bezel, this monitor delivers beautiful HD images. Connect your game console or DVD player through the HDMI input and enjoy HD content on your desktop. High brightness and super-fast 2ms video response and ultra-high 20,000:1 dynamic contrast ratio deliver brilliant, blur-free images with incredible definition and detail. Completing the multimedia desktop experience are integrated stereo speakers with SRS WOW HD stereo sound. The Eco-mode function can save up to 40% on energy costs. The VX2260wm is ideal for the discriminating gamer or professional who demands top-of-the-line images and performance.

Optimize your Desktop Experience

REVIEWS

Windows Magazine, UK

“Awarded to VX2260wm
Widescreen Monitor Group test
Best on Test Award”

First Place

“Awarded to VX2260wm
Widescreen Monitor Group test
Best on Test Award”

“Awarded to VX2260wm
Widescreen Monitor Group test
Best on Test Award ”

“"Plus: Multimedia-Monitor, 16:9-Format und Full-HD-Auflösung, guter Preis. Minus: Nicht höhenverstellbar, schlecht erreichbare Menütasten."”

“Bildqualität (55%): "gut" (1,7); Handhabung (20%):"gut" (2,1); Vielseitigkeit (15%): "gut" (2,0); Umwelteigenschaften (10%): "befriedigend" (2,6). ”

“"Schickes Display für die Filmwiedergabe und Spiele; gute Bildqualität." ”

“Preis/Leistung: "sehr gut" "Plus: gutes Bild; natürliche Farben; gute Verarbeitung. Minus: kein 1.080p/24Hz; schlechter Klang; nervende Betriebs-LED." ”

“Preis/Leistung: "befriedigend" "Schicker Monitor mit vielen Eingängen und Full-HD-Auflösung zum fairen Preis - nur die Boxen sind aus Spielersicht komplett überflüssig." ”

“"Plus: Native Full-HD-Auflösung; Preis. Minus: Maximale Helligkeit." ”

“Awarded to VX2260wm
Widescreen Monitor Group test
Best on Test Award ”

SPECIFICATIONS

COLORS
Black
LCD
Type: 55 cm / 21.5" wide Color TFT Active Matrix LCD
Contrast Ratio: 1000:1 (typ.) ; 20000:1 dynamic
Viewing Angles: 170° (H), 160° (V) at 10:1 c/r / 170° (H), 170° (V) at 5:1 c/r
Brightness: 300cd/m² (typ.)
Display Area: 47.50 cm (18.7") (H) × 26.67 cm (10.5"）(V) /54.6cm (21.5") diagonal
Optimum Resolution: 1920x1080 WUXGA
Response Time: 5ms (on/off) ; 2ms (G to G)
Light Source: Long life, 50,000 hrs. (typ)
Panel Surface: Anti-Glare, Hard coating (3H)
Pixel Pitch: 0.248mm (H)×0.248mm (V)
Colour Support: 16.7 M (6-bits + Hi FRC)
COMPATIBILITY
PC: up to 1920×1080 non-interlaced
Mac®: Power Mac, up to 1920×1080

DIMENSIONS
Physical With Stand: 513mm x 410mm x 208mm (20.2" x 16.1" x 8.2")
Physical Without Stand: 512mm x 330mm x 56mm (20.2" x 13.0" x 2.2")
REGULATIONS
UL, CUL, FCC-B (ICES), CB, CE, CES-003B, VCCI , ERGO (MPR II, ISO 13406-2), NOM, GOST-R, HYGIENIC (20 copies), Energy Star, CCC, BSMI, PSB, C-TICK, MIC (KCC), SASO, WEEE, RoHS, Ukraine, EPEAT Silver
PACKAGE CONTENTS
ViewSonic VX2260wm LCD, VGA cable, DVI cable, Audio cable, Power cable, Quick Start Guide, ViewSonic Wizard CD
AUDIO
Speaker: 2 x 1.5 watt with SRS WOW sound
RECYCLE/DISPOSAL
The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
INPUT
Sync:
Separate Sync / Composite Sync / SOG
Analogue: RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital: DVI-D (TMDS, 100ohms, with HDCP), HDMI (ver.1.3)
Frequency: Fh: 24-83kHz, Fv: 50-76Hz
CONNECTOR
Analogue: 15 pin mini D-sub×1
Digital: DVI-D (with HDCP) / HDMI
Audio (input/output):
3.5 mm Audio line-in / 3.5 mm Audio line-out
Power: 3-pin AC plug (CEE22)
POWER
Voltage: AC 100-240V (Universal); 50/60Hz (Switch)
Consumption: 40 (typ)
Eco Mode: Optimize 34W (typ.) / Conserve 27W (typ.)
Save mode: ≦1W
CONTROLS
Basic: [1], [2], Power, Down, Up
On View (PC mode): Auto image adjust, Contrast/Brightness, Input select: D-SUB, DVI, HDMI PC, HDMI AV, Audio adjust: Volume, mute, Color adjust: sRGB, 9300K, 7500K, 6500K, 5000K, user color [R, G, B], Information, Manual image adjust: H/V position, Horizontal size, fine tune, sharpness, dynamic contrast, response time, aspect ratio, display mode, Eco mode, Setup menu: language, resolution notice, OSD position, OSD timeout, OSD background, sleep, Memory recall
OPERATING CONDITIONS
Temperature: 32–104ºF (0–40ºC)
Humidity: 20–90% (non-condensed)
WEIGHT
Net: 4.1 kg (9.1 lbs)
Gross: 5.6 kg (12.3 lbs)
POWER MANAGEMENT
Meets ENERGY STAR® standards
VESA MOUNT COMPLIANT

VESA 100mm x 100mm
ERGONOMICS
Tilt: 20° ~ -5°
