PJ656

PORTABLE XGA 3LCD PROJECTOR

Sales Enquiry

GALLERY

A versatile, portable projector for professional demands.

With 2000 lumens brightness and a native resolution of 1024 x 768 (XGA), the ViewSonic PJ656 ensures that even the highest professional demands are met. Advanced features such as overscan, 3:2 pull-down, progressive scan and digital keystone correction produce STABLE, CLEAR VIDEO IMAGES for a unforgettable viewing experience. Multiple inputs enhance versatility and thanks to its low weight the PJ656 can quickly be moved from one location to another so that HIGH-RESOLUTION PROJECTION CAN BE ENJOYED IN VIRTUALLY ANY SETTING.

SPECIFICATIONS

COLORS
Black
LCD
Type: 3 x 0.6” P-Si-TFT with Micro lens
Resolution: XGA, 1024 x 768 native (max. 1600 x 1200 compressed)
Lens: Manual focus/zoom
Zoom Factor: 1.2, F1.7 – 1.9 (f=18.9mm – 22.6mm)
Digital Keystone: Vertical ± 15°
COMPATIBILITY
Mac®: Analogue: to SXGA
PC: Analogue: VGA to UXGA (scaled)

DIMENSIONS
W x H x D mm: 306 x 97 x 249
REGULATIONS
Demko/GS, CE, CB, UL, UL60950/C-UL, FCC-B, C-Tick
PACKAGE CONTENTS
3LCD projector, power cables (Europe [Schuko]/UK), 2.0m VGA video
cable, 3.0m RCA video cable, remote control, batteries, soft carry case,
lens cap, Quick Start Guide, ViewSonic Wizard CD-ROM
(User Guide/drivers)
WARRANTY
Please see: www.viewsoniceurope.com/UK/Support/warranty.htm
AUDIO
Speaker: 1 Watt
INPUT SIGNAL
Frequency: Fh: 31 – 106kHz, Fv: 56 – 120Hz
Video: RGB analogue, NTSC M, NTSC 4.43, PAL, SECAM, HDTV (480i/p, 576i/p, 720p, 1080i)
CONNECTOR
Audio Out: 3.5mm stereo mini jack
PC RGB Input: 15-pin mini D-sub (x2)
Composite Video Input: RCA jack
S-Video Input: Mini-Din 4-pin
Component Video Input: RCA jack (set)
PC RGB Output: 15-pin mini D-sub
Audio Input: 3.5mm stereo mini jack
Control: 9-pin D-sub RS-232 (serial)
USB: USB Typ B
POWER
Voltage: AC 100 - 120 / 200 - 240V, 50 / 60Hz (auto switch)
Consumption: 290 watts (typ.)
CONTROLS
OSD: Auto adjust, language (English, French, German, Spanish, Italian,
Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Korean,
Swedish, Russian, Finnish, Polish), brightness, contrast, Gamma, colour
temp, colour, tint, sharpness, progressive, My Memory, aspect ratio,
overscan, H/V position, H phase, H size, colour space, component,
video format, frame lock, information, keystone, Whsiper Mode, mirror
(normal, H:invert,V:invert, H/V:invert), volume, audio, menu position,
osd bright, blank, start up, My Screen, My Screen Lock, message, auto
search, auto off/on, lamp time, filter time, service menu
Physical: Standby on/off, menu, input, reset, H/V keystone
OPERATING CONDITIONS
Temperature: 5 °C to 35 °C
Humidity: 10 % to 85 % (non condensation)
WEIGHT
Net: 2.8kg
DISPLAY
Contrast Ratio : 400:1
Aspect Ratio: 4:3 (native), 16:9
Throw Distance: 0.9m – 11.2m
Throw Ratio: 1.5 ~ 1.8:1
Brightness: 2000 ANSI lumens
Size: 30” - 300” (0.76m – 7.62m) (Diagonal)
Lamp: 180 watts UHB, 2000 hours (Eco mode 3000 hours2)
NOISE LEVEL
Normal: 38 dB (typ.)
Whisper mode: 33 dB (typ.)
OTHER
Auto power off, auto search, freeze & magnifying, progressive scan,
Frame Lock, 3:2 pull-down, vertical keystone adjustment, colour space,
overscan, digital Gamma correction, PIN Lock System, Whisper Mode,
My Screen, My Memory, easy lamp replacement from Top, easy filter
change with sliding system, easy quick on, security bar for Anti-Theft
