VX2262wm

56cm / 22" WIDESCREEN LCD WITH 20,000:1 DYNAMIC CONTRAST

Demande de renseignements sur les ventes

PHOTOS

INTRODUCTION

ViewSonic’s 56cm / 22" VX2262wm widescreen LCD offers the perfect balance of performance and style. With its elegant lines, the VX2262wm fits beautifully into your office décor and its high performance features BLEND EFFORTLESSLY INTO YOUR TECHNOLOGY LIFESTYLE. Images leap from the screen with 1680x1050 resolution, video response as fast as 2msand 20,000:1 DYNAMIC CONTRAST RATIO. Scrolling text, Internet pages and spreadsheet applications are Displayed in crisp, blur-free detail with precise color The SRS WOW HD sound* powerfully complements your games, movies and other multimedia applications. Demanding designers, professionals and gamers will love the sophisticated performance of the 22" VX2262wm.

High performance in a beautiful design

SPÉCIFICATIONS

COLORS
Black
LCD
Type: 56cm / 22" Wide Color TFT Active Matrix LCD
Rapport de contraste: 1000:1 static (typ), 20,000:1 dynamic
Angles de vue: 170º horizontal, 160º vertical @ contrast ratio > 10:1

170° horizontal, 170° vertical @ contrast ratio > 5:1
Luminosité: 300cd/m²
Zone d'affichage: 474mm x 296mm, 16.1" horizontal x 10.0" vertical; 22.0" diagonal
Résolution optimale: 1680x1050
Temps de réponse: up to 2ms (gray-to-gray); 5ms black-to-white (typ)
Source lumière: Long life, 50,000 hrs. (typ)
Surface panneau: Anti-glare
COMPATIBILITÉ
Ordinateur: VGA up to 1680x1050 non-interlaced
Mac®: G3/G4/G5 up to 1680x1050

Dimensions (mm)
Physique avec support: 508mm x 440mm x 203mm (20.0" x 17.3" x 7.9")
Physique sans support: 508mm x 359mm x 64mm (20.2" x 14.1" x 2.5")
NORMES
UL, cUL, FCC-B, CB, CE, ENERGY STAR®, NOM, WEEE TUV-S/IRAM/UL-AR S Mark), ICES-B, ISO 13406-2 & MPR II), GOST-R + 20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, MIC, Green Mark, RoHS, EPEAT-Silver
CONTENU DE L'EMBALLAGE
LCD display, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD
AUDIO
Haut-parleurs: 2x2-watt SRS WOW HD (Requires SRS Audio Sandbox Software to be installed.)
RECYCLAGE/ELIMINATION
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws.
CONNECTEURS
Alimentation: 3-pin AC plug (CEE22)
Analogique/Numérique: 15-pin mini D-sub/DVI-D
Alimentation
Tension: AC 100-240V, 50-60Hz (auto switch)
Consommation: 45W (typ)
COMMANDES
De base: Power, 1, down, up, 2
OnView®: Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch® color adjust (sRGB, 9300K, 7500K, 6500K-default, 5400K, user color-RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number), manual image adjust (H. size, H. position, V. position, fine tune, sharpness, dynamic contrast comma aspect ratio, response time)), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall
CONDITIONS D'EXPLOITATION
Température: 32-104°F (0-40°C)
Humidité: 10-90% (non-condensing)
Poids
Net avec support: 5.6 kg (12.2 lb.)
Net sans support: 4.5 kg (9.9 lb.)
Brut avec support: 7.7 kg (16.9 lb.)
Entrée vidéo
Analogique/Numérique: RGB analog (75 ohms, 0.7 Vp-p)/DVI-D (HDCP)
Fréquence: Fh: 24~83kHz, Fv: 50~76Hz
Synchronisation: H/V separated (TTL), composite, sync-on-green
GESTION ALIMENTATION
Meets MPRII and ENERGY STAR® standards
ERGONOMIE
Inclinaison: -5/+20º
