VX1940w-4

49 cm / 19" WIDESCREEN LCD MONITOR VX SERIES WITH 2MS RESPONSE TIME AND 3,000:1 DCR

Demande de renseignements sur les ventes

PHOTOS

INTRODUCTION

ViewSonic’s 49 cm / 19" VX1940w widescreen LCD delivers unparalleled performance with video response as fast as 2ms, 3000:1 DYNAMIC CONTRAST RATIO (typ.) and SUPER-HD 1680 x 1050 RESOLUTION. Games, HD movies, videos and graphic-intensive applications have never looked better on your desktop. This Vista™ premium certified WIDESCREEN DISPLAY ENHANCES RODUCTIVITY by allowing you to view two documents side-by-side or work in two applications without toggling. Connect your game console, DVD player and other components through the DIGITAL (DVI-D HDCP) AND ANALOGUE INPUTS. The Kensington security port provides theft deterrence and the OSD and power lock prevent unauthorised changes to your optimal screen settings.

Enjoy HD content on your desktop

It’s not just the ultimate HD gaming display. It’s a ViewSonic.

CRITIQUES

Editor's Choice 4 out of 5 Mice

“The ViewSonic VX1940w receives a four-out-of-five, “Great” rating and the Editors’ Choice award in this reviews roundup, highlighting its easy-to-use onscreen controls, resolution and overall image quality.”

SPÉCIFICATIONS

COLORS
Black
LCD
Type: 49 cm / 19" Wide TN colour TFT active matrix WSXGA+ LCD
Rapport de contraste: 1000:1 (typ.), 3000:1 DCR (typ.)
Angles de vue: 170° horizontal, 160° vertical (at 0:1)

170° horizontal, 170° vertical (at 5:1)
Luminosité: 300 cd/m²
Zone d'affichage: 41.0cm horizontal x 25.7cm vertical, 48.3cm diagonal
Résolution optimale: 1680 x 1050@60Hz
Temps de réponse: 2ms (grey-to-grey), 5ms (off-on-off) (typ.)
Source lumière: Long life, 40000 hrs. (typ.)
Surface panneau: Anti-glare
Pas de pixel: 0.243mm
Prise en charge des couleurs: 16.7M colours supported (6-bit+2-bit FRC)
Horloge pixel: 165MHz
COMPATIBILITÉ
Ordinateur: VGA up to 1680 x 1050 non-interlaced
Mac®: Power Mac™ up to 1680 x 1050 non-interlaced

Dimensions (mm)
Physique avec support: 442 x 385 x 195
Physique sans support: 442 x 310 x 54
Emballage (LxHxP): 520 x 469 x 145
NORMES
TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R+Hygienic, UL, cUL, FCC-B, NOM, EPEAT, Ukraine, SASO, ENERGY, ENERGY STAR, C-Tick, MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark, CCC, VCCI, Green Mark, WEEE, RoHS
CONTENU DE L'EMBALLAGE
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
CONNECTEURS
Analogique: 15-pin mini D-Sub (detachable cable)
Numérique: 24-pin DVI-D (detachable cable) (HDCP enabled)
Alimentation: 3-pin AC plug (CEE22)certified)
Alimentation
Tension: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consommation: 44 watt (typ.), <1 watt in power save mode
COMMANDES
De base: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness, aspect ratio [4:3, full screen], response time), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall
CONDITIONS D'EXPLOITATION
Température: 0°C – 40°C
Humidité: 10%–90% (non-condensation)
Poids
Net avec support: 4.6kg
Net sans support: 3.8kg
Brut avec support: 5.8kg
Entrée vidéo
Fréquence: Fh: 24~82kHz, Fv: 50~85Hz
Synchronisation: H/V separate (TTL), composite, sync on green
Analogique: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Numérique: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
GESTION ALIMENTATION
TCO’03 and ENERGY STAR standards
SÉCURITÉ
Kensington® security port
MONTAGE MURAL
VESA FDMI 100mm x 100mm
ERGONOMIE
Inclinaison: Down 5°, Up 20°

TÉLÉCHARGEMENTS

Feuille de données

VX1940w-4 Fiche Produit (version courte)VX1940w-4 Fiche Produit (version complète)
