- Dimensions (mm)
Physique avec support: 524 x 482 x 244
Physique sans support: 524 x 355 x 64
Emballage (LxHxP): 575 x 522 x 150
- NORMES
CE, CB, RGO, ISO 13406-2 (pixel failure class II), UL, cUL, GOST-R+Hygienic, FCC-B, NOM, SASO, ENERGY STAR, C-Tick, BSMI, PSB, TUV-S/IRAM/UL-AR S Mark, MPR II, VCCI, CCC, WEEE, RoHS
- CONTENU DE L'EMBALLAGE
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (multi-language User Guides/drivers and SRS WOW HD software)
- AUDIO
Haut-parleurs: 2 x 2.5 watt integrated stereo speakers with SRS WOW HD
- CONNECTEURS
Analogique: 15-pin mini D-Sub (detachable cable)
Numérique: 24-pin DVI-D (detachable cable) (HDCP enabled)
Alimentation: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in
- Alimentation
Tension: AC 100–240 V, 50–60 Hz (auto switch), internal power supply
Consommation: 36 watt (typ.), <1 watt in power save mode
- COMMANDES
De base: Power, menu [1], select [2], up, down
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), Audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5000K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language [11 options], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- CONDITIONS D'EXPLOITATION
Température: 5°C – 35°C
Humidité: 20% – 80% (non-condensation)
- Poids
Net avec support: 6.0kg
Net sans support: 4.8kg
Emballage: 7.5kg
- Entrée vidéo
Fréquence: Fh: 30–82kHz, Fv: 50–75Hz
Synchronisation: H/V separate (TTL), composite, sync on green
Analogique: RGB analogue (0.7/1.0 Vp-p, 75 ohm, DDC/CI)
Numérique: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
- GESTION ALIMENTATION
Meets ENERGY STAR standards
- SÉCURITÉ
Kensington® security port
- MONTAGE MURAL
VESA FDMI 100mm x 100mm
- ERGONOMIE
Inclinaison: Down 5°, Up 17°
