Feature-rich solution without breaking the bank.
The 43cm / 17" ViewSonic VA712 LCD display features ViewSonic's innovative CLEARMOTIV™ BROADCAST-QUALITY VIDEO WITH DYNAMIC STRUCTURE™ TECHNOLOGY to combine an 8ms video response with vibrant, clear images. This value-positioned display brings tech-savvy users all the bells and whistles they crave without the heavy price tag. Enjoy a true multimedia experience with less clutter and components on the desktop with the all-in-one VA712 LCD – great for mixed data, audio, graphics, video content and games.
The 43cm / 17" ViewSonic VA712 LCD display features ViewSonic's innovative CLEARMOTIV™ BROADCAST-QUALITY VIDEO WITH DYNAMIC STRUCTURE™ TECHNOLOGY to combine an 8ms video response with vibrant, clear images. This value-positioned display brings tech-savvy users all the bells and whistles they crave without the heavy price tag. Enjoy a true multimedia experience with less clutter and components on the desktop with the all-in-one VA712 LCD – great for mixed data, audio, graphics, video content and games.
SPECIFICATIONS
- LCDType: 43cm / 17" colour TFT active matrix SXGA LCD
Rapport de contraste: 350:1 (typ.)
Angles de vue: 160° horizontal, 120° vertical (at 10:1)
160° horizontal, 140° vertical (at 5:1)
Luminosité: 350cd/m² (typ.)
Zone d'affichage: 338mm horizontal x 270mm vertical, 43.2cm diagonal
Résolution optimale: 1280 x 1024
Temps de réponse: 8ms (typ)
Source lumière: Long life, 50,000 hrs. (typ.)
Surface panneau: Anti-glare
Pas de pixel: 0.264mm
Prise en charge des couleurs: 16.2M colours (6-bit +2-bit FRC) - COMPATIBILITÉOrdinateur: VGA up to 1280 x 1024 (up to 75 Hz)
Mac®: Power Mac™ G3/G4/G5 1280 x 1024 (up to 75 Hz) - Dimensions (mm)Larg x prof x htr mm: 386 x 411 x 177 (with stand)
- NORMESCE, CB, GS, ERGO, ISO13406-2 (pixel failure class II), TCO'99, UL, cUL, FCC-B, ENERGY STAR®, NOM, TUV-S, MPR II, GOST-R + 20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK
- AUDIOHaut-parleurs: 2 x 1 watt
- Signal d'entréeFréquence: Fh: 30~82kHz
Fv: 50~85Hz
Vidéo: RGB analogue (75 ohms, 0.7 Vp-p)
Sync: H/V separate (TTL) - CONNECTEURSAnalogique: 15-pin mini D-Sub (captive cable)
Audio: Stereo mini audio line in - AlimentationTension: AC 100–240V (universal), 50–60Hz (auto switch), external power supply
Consommation: 51 Watt (typ.) - COMMANDESOSD: Auto image adjust, brightness, contrast, input selection, ViewMatch® colour adjust (sRGB, 9300K, 6800K, 6500K), information (mode, model number, serial number), audio (volume, mute), manual image adjust (H. position, V.position, fine tune, sharpness), setup menu (language, resolution notice) OSD position, OSD timeout, OSD background, memory recall
Physique: Power on/off, menu, up, down, select - CONDITIONS D'EXPLOITATIONTempérature: 0°C to 40°C
Humidité: 10% to 90% (no condensing) - PoidsNet: 4.3kg
- GESTION ALIMENTATIONMeets TCO'99 and ENERGY STAR® standards
- ERGONOMICSDown 5°, Up 20°
