High Impact 1080p Digital Signage
ViewSonic’s 46” CD4620 Commercial Display delivers STUNNING FULL HIGH DEFINITION CONTENT TO YOUR AUDIENCE FOR THEIR VIEWING PLEASURE. This 1080p LCD panel displays stunning images at almost print-quality resolution in your Digital Signage applications. VGA input and output plus RS-232 input allows you to DAISY CHAIN MULTIPLE DISPLAYS into the signage network and still be able to control each display individually. Other inputs include HDMI, S-VIDEO, COMPONENT, COMPOSITE and PC-VGA. Wide viewing angles, high brightness and contrast and 1920 x 1080 native resolution ensure crystal clear images in virtually any room or lighting conditions. A fast 6ms response time delivers crisp scrolling text or videos. The CD4620 sets a new standard for large format, high impact Digital Signage solutions.
REVIEWS
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
“ViewSonic is reaching into the digital signage space with its CD4620, a 42-inch commercial display that offers 1920 x 1080 high definition resolution, 6-millisecond response time and a 1500:1 contrast ratio.”
SPECIFICATIONS
- COLORSBlack
- LCDType: 117 cm / 46" wide colour TFT active matrix, 1920 x 1080
Rapport de contraste: 1500:1 (typ.)
Angles de vue: 176° horizontal, 176° vertical (at 10:1)
Luminosité: 450cd/m² (typ.)
Surface vitrée: Anti-glare, hard coating (2H)
Zone d'affichage: 101.8 cm horizontal x 57.3cm vertical, 116.8cm diagonal
Temps de réponse: 6ms (grey-to-grey)
Rapport largeur/hauteur: 16:9
Résolution native: 1920 x 1080
Prise en charge des couleurs: 16.7M colours supported (8-bit) - Dimensions (mm)Physique (LxHxP): 1122 x 663 x 138 mm (without stand)
- NORMESCE, CB, GOST, UL/cUL, FCC, NOM, WEEE, RoHS
- CONTENU DE L'EMBALLAGELCD display, 1.8m power cables (Europe [Schuko]/UK), remote control, batteries, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- AUDIOSignal: 2 x 10 watt with SRS TruSurround¹
- Signal d'entréeComp. TV/Vidéo: 480i, 480p, 720p, 1080i, 1080p
Fréquence: Fh: 31-91kHz,
Fv: 50-75Hz
Numérique: HDMI (HDCP enabled; TMDS, 100 ohm)
Sync: H/V separate (TTL) - CONNECTEURSSortie audio: 1 x RCA (left/right)
2 x speaker connectors (for optional speakers)
Entrée vidéo composite: 1 x RCA (CVBS)
Entrée S-vidéo: 1 x 4-pin mini DIN jack (Y/C)
Entrée vidéo composite: 1 x RCA set (YPbPr/YCbCr)
Entrée audio: 1 x 3.5mm mini stereo
2 x RCA (left/right)
Entrée analogique: 1 x 15-pin mini D-Sub (detachable cable)
Sortie analogique: 1 x 15-pin mini D-Sub (detachable cable)
Sortie vidéo composite: 1 x RCA (CVBS)
1 x BNC
Alimentation: 3-pin plug
Commande/Sortie Net: 1 x D-sub RS-232
Commande/Entrée Net: 1 x D-sub RS-232 - AlimentationTension: AC 100–240V (universal), 50/60Hz
Consommation: 285 watt (max.), <5 watt in power save mode - COMMANDESDe base: Power, menu, exit, source, channel +/-, volume +/-, main power switch
OSD: Picture Menu (brightness, contrast, sharpness, black level, NR, tint, colour, colour temperature [10500K, 9300K, 7500K, 6500K, User-RGB], picture reset), Screen Menu (H/V position, H size, fine tune, zoom [H&V zoom, H zoom, V zoom, H/V zoom position], screen reset), Audio Menu (balance, treble, bass), PIP Menu (PIP size, PIP audio source, PIP reset), Configuration Menu (auto setup, auto adjust, power save, language [English, French, German, Russian, Simplified Chinese, Spanish], screen saver, colour TV system, OSD turn off, information OSD, off timer, OSD H/V position, display information, config. reset), Advanced Menu (input resolution, black level expansion, Gamma, scan mode, scan conversion, film mode, remote control, display ID, tiling [H/V monitors, position, frame compensation, enable], date/time, auto on/off scheduler [day, hour, minute, input], DDC/CI, advanced reset) - CONDITIONS D'EXPLOITATIONTempérature: 0°C–40°C
Humidité: 10–85% (non-condensing) - PoidsNet: 34.6kg (with optinal stand), 29.3kg (without stand)
Brut: 35.9kg - Entrée vidéoAnalogique/Numérique: HDMI (x2), S-video, component, composite, RCA (x2)
- MONTAGE MURALVESA FDMI 400mm x 200mm, M6 screws
