- DIMENSIONS
Physical With Stand: 524 x 482 x 244
Physical Without Stand: 524 x 355 x 64
W x H x D mm: 575 x 522 x 150
- REGULATIONS
CE, CB, RGO, ISO 13406-2 (pixel failure class II), UL, cUL, GOST-R+Hygienic, FCC-B, NOM, SASO, ENERGY STAR, C-Tick, BSMI, PSB, TUV-S/IRAM/UL-AR S Mark, MPR II, VCCI, CCC, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (multi-language User Guides/drivers and SRS WOW HD software)
- AUDIO
Speaker: 2 x 2.5 watt integrated stereo speakers with SRS WOW HD
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable) (HDCP enabled)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in
- POWER
Voltage: AC 100–240 V, 50–60 Hz (auto switch), internal power supply
Consumption: 36 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], select [2], up, down
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), Audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5000K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language [11 options], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 5°C – 35°C
Humidity: 20% – 80% (non-condensation)
- WEIGHT
Net With Stand: 6.0kg
Net Without Stand: 4.8kg
Packaging: 7.5kg
- VIDEO INPUT
Frequency: Fh: 30–82kHz, Fv: 50–75Hz
Sync: H/V separate (TTL), composite, sync on green
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm, DDC/CI)
Digital: DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI)
- POWER MANAGEMENT
Meets ENERGY STAR standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, Up 17°
