- DIMENSIONS
Physical With Stand: 428 x 457-537 x 230
Physical Without Stand: 428 x 399 x 68
W x H x D mm: 486 x 590 x 278
- REGULATIONS
TCO’03, GS, Ergo, ISO13406-2 (pixel failure class II), CE, CB, GOST-R, PSB, ENERGY STAR ,UL/cUL, FCC-B, ICES 003, SASO, BSMI, C-Tick, CCC, WEEE, RoHS
- PACKAGE CONTENTS
LCD Monitor, power cable, D-sub video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)
- AUDIO
Speaker: 2 x 1.5 watt integrated stereo speakers
Amplifier: 3 watts @ 1khz @ THD ≤ 8%
- CONNECTOR
Analogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in
- POWER
Voltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 35 watt (typ.), <1 watt in power save mode
- CONTROLS
Basic: Power, menu [1], up, down, select [2], mute
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall
- OPERATING CONDITIONS
Temperature: 0° to 40°
Humidity: 10% to 90% (non-condensing)
- WEIGHT
Net With Stand: 6.0kg
Gross: 7.2kg
- VIDEO INPUT
Frequency: Fh: 24-82kHz, Fv: 50–75Hz
Sync: H/V separate (TTL)
Analogue: RGB analogue (0.7 Vp-p , 75 ohm)
Digital: DVI-D (TMDS, 100 ohms)
- POWER MANAGEMENT
Meets TCO’03 and ENERGY STAR® standards
- SECURITY
Kensington® security port
- VESA MOUNT COMPLIANT
VESA FDMI 100mm x 100mm
- ERGONOMICS
Tilt: Down 5°, up 20°
Swivel: 360° swivel base
Height Adjustment: 0~80mm
The 48cm / 19" ViewSonic VG930m LCD monitor is the ultimate value LCD business display. Featuring height adjustment, tilt and 360° swivel features, the VG930m allows the user to set the ergonomic position of the monitor to generate the best possible viewing position and greatest viewing comfort. Image quality is guaranteed with premium contrast and brightness levels to deliver superb pictures with vivid, brilliant colours and crisp detail. Digital and analogue inputs ensure maximum connectivity and integrated stereo speakers provide space-saving high quality sound to your desktop. The full featured VG930m is the ideal LCD monitor for business, home office, government or education use.
