- DIMENSIONS
Physical (mm): 422.4mm x 438.5mm x 180.6mm (with stand)
422.4mm x 382.1mm x 62mm (without stand)
- REGULATIONS
TCO ́03, TÜV/GS, ISO 13406-2 (class 2) TÜV-S, TÜV/Ergo, UL, CUL, FCC-B, CB REPORT, CE, EPA, NOM, NEMKO, SEMKO, DEMKO, FIMKO, GOST-R, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, ENERGY
- AUDIO
Speaker: 2x3-watts
Amplifier: 3 watts @1kHz
- CONNECTOR
Power: 3-pin AC plug
Analogue/Digital: 15-pin mini D-sub, DVI-D
Audio: 3.5mm audio line-in
- POWER
Voltage: AC 100–240V, 50–60Hz internal power supply
Consumption: < 50 W (typ); ≤ 1 watt in power save mode
- CONTROLS
Basic: Power (soft), 1, down, up, 2, mute, volume up, volume down
OSD: Auto image adjust, contrast, brightness, input select, audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K- default, 5400K, 5000K, user colour), information (mode, model number, serial number), balance, bass, treble, manual image adjust (H. size, H. position, V. position, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout), OSD background, memory recall
- OPERATING CONDITIONS
Temperature: 0–40°C
Humidity: 10–90% (non-condensing)
- WEIGHT
Net: 6.8 kg
- VIDEO INPUT
Frequency: Fh: 30~82kHz, Fv: 50~85Hz
Analogue: RGB Analogue (75 ohms, 0.7 Vp-p)
Digital: DVI-D (TMDS, 100 ohms)
Sync: H/V separated (TTL)
- POWER MANAGEMENT
Meets TCO, Energy Star and ENERGY standards.
