OVERVIEW
The 17” ViewSonic VG730m LCD monitor is the ultimate value LCD business display. Featuring height adjustment, tilt and 360° swivelfeatures, the VG730m allows the user to set the ergonomic position of the monitor to generate the best possible viewing position andgreatest viewing comfort. Image quality is guaranteed with premium contrast and brightness levels to deliver superb pictures with vivid, brilliant colours and crisp detail. Digital and analogue inputs ensure maximum connectivity and integrated stereo speakers provide space-saving high quality sound to your desktop. The full featured VG730m is the ideal LCD monitor for business, home office, government or education use.Digital performance and ergonomic adjustability
It’s not just a multimedia LCD. It’s a ViewSonic.
REVIEWS
SPECIFICATIONS
- COLORSBlack
- LCDType: 43cm / 17" TN colour TFT active matrix SXGA LCD
Contrast Ratio: 600:1 (typ.)
Viewing Angles: 150° horizontal, 145° vertical (at 10:1)
170° horizontal, 155° vertical (at 5:1)
Brightness: 280cd/m² (typ.)
Display Area: 33.8cm (horizontal) x 27.0cm (vertical), 43.2cm diagonal
Optimum Resolution: 1280 x 1024@60Hz
Response Time: 8ms (off-on-off) (typ.)
Light Source: Long life, 50,000 hrs. (typ)
Panel Surface: Anti-glare (3H)
Pixel Pitch: 0.264mm
Colour Support: 16.7M colours supported (6-bit + 2-bit FRC)
Pixel Clock: 140MHz - COMPATIBILITYPC: VGA up to 1280 x 1024 non-interlaced
Mac®: Power Mac™ up to 1280 x 1024 non-interlaced
- DIMENSIONSPhysical With Stand: 387 x 475-555 x 230
Physical Without Stand: 387 x 367 x 67
W x H x D mm: 445 x 552 x 278 - REGULATIONSTCO’03, GS, Ergo, ISO13406-2 (pixel failure class II), CE, CB, GOST-R, PSB, ENERGY STAR,YCO03, UL/cUL, FCC-B, ICES 003, NOM, TUV-S/IRAM/UL-AR S Mark, SASO, BSMI, C-Tick, MIC, CCC, WEEE, RoHS
- PACKAGE CONTENTSLCD Monitor, power cable, D-sub video cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/ drivers) (multi-language) - AUDIOSpeaker: 2 x 1.5 watt integrated stereo speakers
- CONNECTORAnalogue: 15-pin mini D-Sub (detachable cable)
Digital: 24-pin DVI-D (detachable cable)
Power: 3-pin AC plug (CEE22)
Audio: 3.5mm stereo audio line-in - POWERVoltage: AC 100–240V, 50/60Hz (auto switch), internal power supply
Consumption: 35 watt (typ.), <1 watt in power save mode - CONTROLSBasic: Power, menu [1], up, down, select [2], mute
OSD: Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K,
user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall - OPERATING CONDITIONSTemperature: 5°C–35°C
Humidity: 20%–80% (non-condensation) - WEIGHTNet With Stand: 5.0kg
Gross: 6.9kg - VIDEO INPUTFrequency: Fh: 30–82kHz, Fv: 50–75Hz
Sync: H/V separated (TTL)
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm)
Digital: DVI-D (TMDS, 100 ohms) - POWER MANAGEMENTMeets TCO’03 and ENERGY STAR standards
- SECURITYKensington security port
- VESA MOUNT COMPLIANTVESA FDMI 100mm x 100mm
- ERGONOMICSTilt: Down 5°, up 20°
Swivel: 360° swivel base
Height Adjustment: 0~80mm
